Newtek Vizrt Tricaster 2 Elite 40-Input 4K/60 Multi-Definition Production Switcher / Graphics / Streaming System

The NewTek Vizrt TriCaster 2 Elite is a comprehensive live production system capable of capturing and delivering content across SD, HD, and UHD 4K formats. Purpose-built for professional broadcast workflows, it serves as a centralized production hub integrating camera inputs, graphics, switching, and streaming capabilities into a single unified platform.

View Product Features

  • 32-Channel NDI Video Switcher, 3 RU Form
  • SD, HD & UHD 4K Resolution Support
  • 8 x 3G/HD/SD-SDI Inputs up to 1080p
  • Supports Control of up to 32 x PTZ Cams
  • Video Conference Software Integration
  • Digital Audio Mixer with 4x4x4 Routing
  • 8 x HD, 2 x UHD 4K, 48 x NDI Outputs
  • 4 x MultiViewer Outputs
  • 2 x Streaming Outputs, 8 x SDI Outputs
  • Keyers, M/E Buses, Audio Mixer, Macros

Already own this item and want to sell it?

About the Newtek Vizrt Tricaster 2 Elite 40-Input 4K/60 Multi-Definition Production Switcher / Graphics / Streaming System

The NewTek Vizrt TriCaster 2 Elite is a comprehensive live production system capable of capturing and delivering content across SD, HD, and UHD 4K formats. Purpose-built for professional broadcast workflows, it serves as a centralized production hub integrating camera inputs, graphics, switching, and streaming capabilities into a single unified platform.

The system accommodates diverse content genres—from sports and live events to worship services and talk programming—while maintaining broadcast-quality output standards. Its integrated architecture streamlines production complexity by consolidating multiple hardware components and workflows, enabling operators to manage sophisticated multi-camera productions with efficiency and reliability.

Key Features

  • 32-Channel NDI Video Switcher, 3 RU Form
  • SD, HD & UHD 4K Resolution Support
  • 8 x 3G/HD/SD-SDI Inputs up to 1080p
  • Supports Control of up to 32 x PTZ Cams
  • Video Conference Software Integration
  • Digital Audio Mixer with 4x4x4 Routing
  • 8 x HD, 2 x UHD 4K, 48 x NDI Outputs
  • 4 x MultiViewer Outputs
  • 2 x Streaming Outputs, 8 x SDI Outputs
  • Keyers, M/E Buses, Audio Mixer, Macros

Newtek Vizrt Tricaster 2 Elite 40-Input 4K/60 Multi-Definition Production Switcher / Graphics / Streaming System Specs

Mix Effects
Available M/E Layers:
8 M/E
Audio Mixing
8-Channel Mixing
Processing
Switching Type
Software
Processing Resolution
UHD 4K at 60
Color Processing
4:4:4YCbCr
Audio Processing
96 kHz
Input
Number of Video Input Sources
32
Video Inputs
2x RJ45 (NDI) Female, 8x BNC (3G-SDI) Female
Audio Inputs
2x XLR 3-Pin Mono Female, 3x 1/4" TS Stereo Female, 1x 1/8" / 3.5 mm TS Mono Female
Output
Video Output Channels
48
Video Outputs
1x RJ45 (NDI) Female, 8x BNC (3G-SDI) Female
Audio Outputs
2x XLR 3-Pin Mono Analog Male, 1x TOSLINK Stereo S/PDIF Female, 2x 1/4" Balanced TS Mono Female, 1x 1/4" Balanced TS Stereo Female, 3x 1/8" / 3.5 mm TS Mono Female

Key Features

  • 32-Channel NDI Video Switcher, 3 RU Form
  • SD, HD & UHD 4K Resolution Support
  • 8 x 3G/HD/SD-SDI Inputs up to 1080p
  • Supports Control of up to 32 x PTZ Cams
  • Video Conference Software Integration
  • Digital Audio Mixer with 4x4x4 Routing
  • 8 x HD, 2 x UHD 4K, 48 x NDI Outputs
  • 4 x MultiViewer Outputs
  • 2 x Streaming Outputs, 8 x SDI Outputs
  • Keyers, M/E Buses, Audio Mixer, Macros
