Optical System & Light Source
Pixel Array
12 individually addressable high-power LED pucks
LEDs per Pixel
RGBAW+UV (Red, Green, Blue, Amber, White, Ultraviolet)
Total LED Count
72 LEDs (12 pucks x 6 colors)
Pixel Control
Individual pixel addressability for graphic effects
Primary Function
High-output color wash and pixel-mappable effects
Beam Angle per Pixel
Wide field (typically ~25°)
Color Mixing
Full RGBAW+UV mixing for maximum color gamut
White Light
Variable color temperature white from Amber/White LED mix
UV Effect
Dedicated Ultraviolet LEDs for fluorescent/blacklight effects
Dimming
0-100% smooth dimming, per pixel or global
Strobe
Electronic strobe effect
Control Protocol
DMX-512, RDM
Pixel Mapping
Full individual pixel control via high-channel-count DMX modes or Art-Net/sACN
Network Port
RJ45 Ethernet for Art-Net, sACN, or proprietary network protocols
DMX Channels
Multiple modes: e.g., 8, 20, 44, 92, or 188 channels
188-Channel Mode
Full individual control (12 pucks x 6 colors = 72, plus control channels)
Control Modes
DMX, Network, Master/Slave, Standalone
IP Rating
IP65 (Dust-tight and protected against water jets)
Housing
Heavy-duty die-cast aluminum, fully sealed
Power Supply
Auto-switching 100-240V AC, 50/60Hz
Power Consumption
~240 Watts
Power Connection
PowerCON TRUE1 In and Out (linkable)
Cooling
IP65-rated, temperature-controlled forced-air cooling
Weight
Approx. 12.5 kg (27.5 lbs)
Dimensions (Hexagon)
Approx. 430 mm (17") across flats, depth ~200 mm (7.9")
Mounting
Multiple 1/4"-20 and M10 mounting points on rear, integrated yoke options may vary
Data Connections
3-pin & 5-pin XLR DMX In/Out, RJ45 Ethernet
Display
LCD screen for addressing and configuration
Software Updates
Firmware upgradable via USB or network
Lens
Sealed, durable diffuser lens over each pixel puck
Effects Engine
Built-in auto programs for pixel chases and color effects
Thermal Protection
Over-temperature monitoring and automatic brightness adjustment
Safety Certifications
ETL, CE certified
Typical Use
Architectural facade lighting, outdoor stages, theme parks, permanent concert venues, pixel-mapped installations.
