Fostex

Fostex D-15 Professional Timecode DAT

$0.00

The Fostex D-15 is a professional timecode DAT (Digital Audio Tape) recorder known for its affordability and features tailored for sound and video production. It offers timecode capabilities, including SMPTE timecode support, video reference, and RS-422 control options.

View Product Features

  • Supports SMPTE timecode and LTC/A-Time output
  • Sync via external video or Word Clock
  • RS-422 remote control (D-15TCR model)
  • XLR, RCA, AES/EBU, and optical S/PDIF audio I/O
  • 8 Mbit RAM buffer for instant start and cueing
Out of Stock
0 in stock

Once stock replenishes, inventory will display below.

Already own this item and want to sell it?

About the Fostex D-15 Professional Timecode DAT

The Fostex D-15 is a professional digital audio tape (DAT) recorder engineered for critical recording, editing, and mastering applications where precise timecode synchronization is paramount. Designed for post-production studios, broadcast facilities, and film/TV sound departments, it utilizes the Rotary Head Digital Audio Tape (R-DAT) format to deliver 16-bit linear PCM audio with the fidelity and robustness required for professional workflows. A defining feature is its comprehensive timecode system, supporting both longitudinal timecode (LTC) recorded on an optional track and vertical interval timecode (VITC) for video synchronization, allowing the D-15 to operate as a master or slave device within complex video, audio, and film editing suites. Its transport offers the precise cueing and variable-speed playback necessary for locating edit points and conforming audio to picture.

The recorder provides a sophisticated set of professional features tailored for editing and synchronization. It offers a ±12.5% vari-speed control for pitch adjustment or sync matching, and its auto-locate function can store and recall multiple cue points with frame accuracy. The unit supports both standard 48 kHz and 44.1 kHz sampling rates, and includes digital inputs and outputs (AES/EBU and S/PDIF) to maintain a fully digital signal path when interfacing with digital mixers, workstations, or other DAT machines. For monitoring and editing, it features a large fluorescent display showing timecode, audio levels, and status information, alongside dedicated buttons for transport control, track arming, and punch-in/out operations, facilitating a hands-on editing process.

Built into a substantial half-rack desktop chassis, the D-15 is constructed with a focus on durability and operational precision. Its front-loading mechanism is designed for reliability, and the unit includes balanced analog XLR I/O in addition to its digital connections. The inclusion of a sync input for video reference black burst ensures stable, drift-free operation in video post-production environments. As a dedicated, high-precision digital recorder, the Fostex D-15 represents the peak of the professional DAT format, offering broadcast-quality audio, frame-accurate synchronization, and the editing capabilities essential for demanding audio-for-video and mastering tasks before the widespread adoption of disk-based workstations.

Key Features

  • Supports SMPTE timecode and LTC/A-Time output
  • Sync via external video or Word Clock
  • RS-422 remote control (D-15TCR model)
  • XLR, RCA, AES/EBU, and optical S/PDIF audio I/O
  • 8 Mbit RAM buffer for instant start and cueing

Fostex D-15 Professional Timecode DAT Specs

Recording Format
Tape Format
R-DAT (Rotary Head Digital Audio Tape)
Tape Speed
8.15 mm/sec
Record Time
120 Minutes (LP Mode), 90 Minutes (SP Mode)
Audio Performance
Sampling Frequencies
48 kHz, 44.1 kHz (Selectable)
Quantization
16-bit Linear PCM
Frequency Response
20 Hz - 22 kHz (±0.5 dB)
Dynamic Range
>90 dB
THD+N
<0.05%
Timecode & Synchronization
Timecode Types
LTC (Longitudinal), VITC (Vertical Interval)
Timecode Track
Optional (for LTC Record/Playback)
Sync Reference
Video Black Burst (for VITC Genlock)
Vari-Speed Range
±12.5%
Inputs & Outputs
Analog I/O
XLR Balanced (Line Level)
Digital I/O
AES/EBU (XLR), S/PDIF (RCA Optical)
Headphone Output
1/4-inch Stereo with Level Control
Editing & Control
Auto-Locate Memories
10
Punch In/Out
Manual or Auto
Display
Fluorescent (Timecode, Level, Status)
Physical & Power
Chassis
Half-Rack Desktop
Dimensions (W x H x D)
220 x 105 x 340 mm
Weight
5.2 kg
Power Requirements
100-120V / 220-240V AC, 50/60 Hz

Key Features

  • Supports SMPTE timecode and LTC/A-Time output
  • Sync via external video or Word Clock
  • RS-422 remote control (D-15TCR model)
  • XLR, RCA, AES/EBU, and optical S/PDIF audio I/O
  • 8 Mbit RAM buffer for instant start and cueing
