CHAUVET Professional COLORdash PAR Bar 4 RGBAW+UV LED Wash Lighting System

$1,103.10

Items Included

Item Notes

Condition: Out of stock
Once stock replenishes, inventory will display below.
Price
Sold out
Pre-Owned Guarantee 14 Day Return Window
Trade-In & SAVE Click Here To Get Started

Description

The CHAUVET Professional COLORdash PAR Bar 4 delivers powerful RGBAW+UV color mixing in a compact, linear format. This LED wash system combines red, green, blue, amber, white, and ultraviolet channels for unlimited color possibilities and creative effects. Perfect for stages, clubs, events, and installations, it offers smooth dimming, color transitions, and intuitive control via DMX or standalone modes. Energy-efficient LED technology ensures long-lasting performance with minimal heat output. Mount individually or link multiple units for seamless coverage across larger spaces. Read more

Features

  • Complete System: 4-head wash lighting system featuring high-power RGBAW-UV LED arrays producing nearly 18,000 total lumens
  • Directional Flexibility: Each of the four individual par heads can be independently focused for tailored stage coverage
  • Beam Shaping: Includes four-leaf barndoors and removable wide filters to adjust beam angles from 15° to 30°
  • Broadcast Ready: Selectable PWM frequencies (up to 25,000 Hz) to eliminate camera flicker during video recording
  • Network Integration: Supports DMX and RDM protocols with dual connectivity options via 5-pin XLR or Neutrik etherCON ports

Business Financing Options Avaiable

View Available Financing

The CHAUVET Professional COLORdash PAR Bar 4 delivers powerful RGBAW+UV color mixing in a compact, linear format. This LED wash system combines red, green, blue, amber, white, and ultraviolet channels for unlimited color possibilities and creative effects. Perfect for stages, clubs, events, and installations, it offers smooth dimming, color transitions, and intuitive control via DMX or standalone modes. Energy-efficient LED technology ensures long-lasting performance with minimal heat output. Mount individually or link multiple units for seamless coverage across larger spaces. Read more

Features

  • Complete System: 4-head wash lighting system featuring high-power RGBAW-UV LED arrays producing nearly 18,000 total lumens
  • Directional Flexibility: Each of the four individual par heads can be independently focused for tailored stage coverage
  • Beam Shaping: Includes four-leaf barndoors and removable wide filters to adjust beam angles from 15° to 30°
  • Broadcast Ready: Selectable PWM frequencies (up to 25,000 Hz) to eliminate camera flicker during video recording
  • Network Integration: Supports DMX and RDM protocols with dual connectivity options via 5-pin XLR or Neutrik etherCON ports

Recommended Accessories

    No products currently in stock

Frequently Purchased Together

    No products currently in stock

About the CHAUVET Professional COLORdash PAR Bar 4 RGBAW+UV LED Wash Lighting System

The Chauvet Professional COLORdash PAR Bar 4 is a complete, high-output all-in-one wash lighting system tailored for small theaters, multi-use venues, and touring events where rapid setup and versatility are essential. Featuring four independently focusable LED heads mounted on a single bar, it utilizes powerful hex-color RGBAW-UV arrays to generate a broad, saturated color palette including rich pastels and true ultraviolet effects. Advanced internal optics ensure smooth, even color mixing across the entire system without visible hot spots or unwanted chromatic separation.

Designed for maximum operational convenience and precision control, the system ships equipped with dedicated four-leaf barndoors and snap-in wide filters for comprehensive beam shaping. It features an intuitive rear OLED touchscreen interface with password protection alongside flexible data connections via standard 5-pin XLR or Neutrik etherCON ports. With selectable electronic dimming curves, adjustable Pulse Width Modulation (PWM) frequencies for flicker-free on-camera broadcast performance, and a built-in tripod adapter, this lightweight fixture package delivers professional-grade flexibility for any stage environment

Key Features

  • Complete System: 4-head wash lighting system featuring high-power RGBAW-UV LED arrays producing nearly 18,000 total lumens
  • Directional Flexibility: Each of the four individual par heads can be independently focused for tailored stage coverage
  • Beam Shaping: Includes four-leaf barndoors and removable wide filters to adjust beam angles from 15° to 30°
  • Broadcast Ready: Selectable PWM frequencies (up to 25,000 Hz) to eliminate camera flicker during video recording
  • Network Integration: Supports DMX and RDM protocols with dual connectivity options via 5-pin XLR or Neutrik etherCON ports

Already own this item and want to sell it?

Click here to sell your item

CHAUVET Professional COLORdash PAR Bar 4 RGBAW+UV LED Wash Lighting System Specs

Light Output
17,930 Lumens (Total system output)
Illuminance
1,482 lux @ 5 m (Narrow, single par)
Beam Angle
15.3° to 30.4° (with included wide filter)
Control Protocols
DMX, RDM
DMX Channels
6, 8, 9, 14, 24, 32, 36, or 41
Selectable PWM
600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
Power Consumption
551 W, 4.63 A @ 120 V, 60 Hz
Power Linking
Up to 2 units @ 120 V; up to 4 units @ 208/230 V

Key Features

  • Complete System: 4-head wash lighting system featuring high-power RGBAW-UV LED arrays producing nearly 18,000 total lumens
  • Directional Flexibility: Each of the four individual par heads can be independently focused for tailored stage coverage
  • Beam Shaping: Includes four-leaf barndoors and removable wide filters to adjust beam angles from 15° to 30°
  • Broadcast Ready: Selectable PWM frequencies (up to 25,000 Hz) to eliminate camera flicker during video recording
  • Network Integration: Supports DMX and RDM protocols with dual connectivity options via 5-pin XLR or Neutrik etherCON ports

Already own this item and want to sell it?

Click here to sell your item

FAQs about CHAUVET Professional COLORdash PAR Bar 4 RGBAW+UV LED Wash Lighting System

What type of light source does the COLORdash PAR Bar 4 use?

The fixture is a complete wash solution featuring four independently focusable LED heads. Each head is equipped with a high-power hex-color (RGBAW-UV) LED array. This configuration allows you to mix a massive palette of deep saturated colors, natural whites, and brilliant ultraviolet effects.

Can the individual heads be adjusted for different targets?

Yes. Unlike static batten fixtures, each of the four light heads can be manually focused and aimed completely independently of the others. This allows you to wash a stage, light a backdrop, and spotlight a performer simultaneously from a single fixture.

What are the beam angle options for this system?

The native optics on each head provide a tight 15.3° beam angle (with a 30° field angle) for concentrated output. However, the system also includes slide-in wide filters for each head, which easily expand the beam angle to a broader 29.8° (with a 49° field angle) for wider stage coverage.

How can I shape the light and prevent spill onto unwanted areas?

To give you precise control over your light shaping, the fixture comes equipped with a dedicated set of four-leaf barn doors for each of the four heads, allowing you to easily flag off the beam edges.

Is the COLORdash PAR Bar 4 suitable for broadcast and film applications?

Absolutely. To prevent any flickering on camera, the advanced electronics offer user-selectable Pulse Width Modulation (PWM) frequencies ranging from 600 Hz all the way up to 25,000 Hz. This makes it highly adaptable to various video shutter speeds and perfect for on-camera productions.

What are my DMX control and data connection options?

The fixture supports both DMX and RDM (Remote Device Management) protocols. For rigging flexibility, it includes standard 5-pin XLR input and output ports, as well as a Neutrik etherCON port that allows for reliable DMX control over a standard CAT6 Ethernet cable.

How smooth is the dimming on this fixture?

It is designed for professional theatrical use, delivering exceptionally smooth fades without any visible choppiness at the bottom of the dimming range. It features four selectable electronic dimming curves to seamlessly integrate into your existing lighting rig.

Does the system have an onboard control menu?

Yes. The main bar chassis features an easy-to-read OLED touchscreen display. This allows for quick, intuitive navigation of settings, DMX addressing, and standalone color mixing, and it can be password-protected to prevent unauthorized tampering.

How many fixtures can I daisy-chain for power?

The fixture utilizes secure, IP-rated Seetronic Powerkon connections. Because it draws around 551W at 120V, you can safely power-link up to 2 units on a standard 120V circuit. On a 208V or 230V circuit, you can daisy-chain up to 4 units together.
