SKU: NE8250.70BD

Ashly ne8250.70BD 8-Channel Amplifier with OPDante and OPDAC8

$3,279.00

Items Included

Ashly ne8250.70BD 8-Channel Amplifier with OPDante and OPDAC8

Item Notes

Condition: Fully Working 5 available
5 available View All
Note: Each item is unique. please check individual listings for details.
Title
Add to cart
Pre-Owned Guarantee 14 Day Return Window

Description

The Ashly ne8250.70BD is a 250-watt Constant Voltage 70V @ 4 Ohm, eight-channel amplifier with OPDante and OPDACA. Connecting and controlling an amplifier for networked systems has now been simplified with Ashly’s NE Series amplifiers. Network Enabled (NE) amplifiers offer ease of use, setup and control using standard 10/100 Ethernet protocol and Protea NE Software. No special outboard control units are needed. Additionally, each amplifier also provides DC voltage control of the attenuators which makes it a snap to control volume from remote locations, preset recall, Remote Power Standby and data in and out ports for connecting accessories like the WR-5 to control user selected parameters. There are LED indicators for power, standby, protect, network communications and each channel has a four-step signal meter, bridge mono, temperature and current indicators. Read more

Features

  • 8 Channel Amplifier
  • Voltage 70V Version
  • OPDante and OPDAC4 Option Cards
  • DC voltage remote gain control
  • Ethernet remote control and monitoring
  • Switch mode supply, Class-D output
  • Stepped, calibrated input attenuators
  • Remote turn on/off
  • Disable all front panel controls via software
  • Temperature-sensitive variable speed fan with side-to-front airflow
  • Selectable HPF frequencies
  • Low Impedance
  • 4-stage level meters
  • Output current and temp indicators
  • Safety/Compliance: TUV, CE, FCC,RoHS

Business Financing Options Avaiable

The Ashly ne8250.70BD is a 250-watt Constant Voltage 70V @ 4 Ohm, eight-channel amplifier with OPDante and OPDACA. Connecting and controlling an amplifier for networked systems has now been simplified with Ashly’s NE Series amplifiers. Network Enabled (NE) amplifiers offer ease of use, setup and control using standard 10/100 Ethernet protocol and Protea NE Software. No special outboard control units are needed. Additionally, each amplifier also provides DC voltage control of the attenuators which makes it a snap to control volume from remote locations, preset recall, Remote Power Standby and data in and out ports for connecting accessories like the WR-5 to control user selected parameters. There are LED indicators for power, standby, protect, network communications and each channel has a four-step signal meter, bridge mono, temperature and current indicators. Read more

Features

  • 8 Channel Amplifier
  • Voltage 70V Version
  • OPDante and OPDAC4 Option Cards
  • DC voltage remote gain control
  • Ethernet remote control and monitoring
  • Switch mode supply, Class-D output
  • Stepped, calibrated input attenuators
  • Remote turn on/off
  • Disable all front panel controls via software
  • Temperature-sensitive variable speed fan with side-to-front airflow
  • Selectable HPF frequencies
  • Low Impedance
  • 4-stage level meters
  • Output current and temp indicators
  • Safety/Compliance: TUV, CE, FCC,RoHS

About the Ashly ne8250.70BD 8-Channel Amplifier with OPDante and OPDAC8

The Ashly ne8250.70BD is a sophisticated eight-channel network amplifier that integrates high-efficiency Class-D power stages, comprehensive DSP, and native Dante digital audio networking into a unified 1U platform. Designed for large-scale commercial distributed audio systems, it delivers 250 watts per channel into a 70V constant-voltage configuration, making it an ideal centralized power source for extensive zones of ceiling and pendant speakers in retail complexes, airports, hotels, and corporate facilities. The amplifier's intelligence is driven by Ashly's Protea DSP, which provides per-channel processing including parametric EQ, crossover filters, dynamics, and delay, enabling precise acoustic optimization for each speaker zone directly within the amplifier without external processors.

A defining feature of this model is the integrated OPDante and OPDAC8 modules, which provide a complete Dante audio network endpoint and high-quality digital-to-analog conversion. This allows the amplifier to receive uncompressed, multi-channel digital audio streams directly over a standard Ethernet network from any Dante-enabled source, such as a digital mixer or audio processor, eliminating the need for separate analog audio cabling and preserving signal integrity. Full network control and monitoring are facilitated through a Gigabit Ethernet port, enabling remote configuration, real-time status monitoring of all channels (including thermal and signal levels), preset recall, and integration with third-party control systems via protocols like SNMP and Telnet.

Built for 24/7 reliability in continuous operation, the amplifier features a convection-cooled, fanless design that ensures silent performance—a critical requirement for noise-sensitive environments. Its compact 1U rack-mountable chassis represents a significant space saving compared to using separate components for amplification, DSP, and audio networking. By converging Dante audio transport, high-resolution DSP, and multi-zone power amplification into one streamlined, network-manageable unit, the Ashly ne8250.70BD provides a powerful, scalable, and future-proof audio backbone for the most demanding professional installed sound applications, offering unparalleled system simplicity, control, and audio fidelity.

Key Features

  • 8 Channel Amplifier
  • Voltage 70V Version
  • OPDante and OPDAC4 Option Cards
  • DC voltage remote gain control
  • Ethernet remote control and monitoring
  • Switch mode supply, Class-D output
  • Stepped, calibrated input attenuators
  • Remote turn on/off
  • Disable all front panel controls via software
  • Temperature-sensitive variable speed fan with side-to-front airflow
  • Selectable HPF frequencies
  • Low Impedance
  • 4-stage level meters
  • Output current and temp indicators
  • Safety/Compliance: TUV, CE, FCC,RoHS

Ashly ne8250.70BD 8-Channel Amplifier with OPDante and OPDAC8 Specs

Amplifier Performance
Channels
8
Amplifier Technology
Class-D
Power per Channel
250W @ 70V
Frequency Response
20Hz - 20kHz
Digital Audio & DSP
Audio Network
Integrated Dante (OPDante)
D/A Conversion
Integrated 8-ch DAC (OPDAC8)
Processing Platform
Protea DSP
Processing per Channel
EQ, Crossover, Dynamics, Delay
Output Configuration
Output Mode
Constant Voltage (70V/100V/25V)
Direct Impedance
4 Ohms
Total Harmonic Distortion
<0.5%
Network & Control
Network Interface
Gigabit Ethernet
Management Software
Ashly Protea
Protocols
Dante, TCP/IP, SNMP
Physical & Power
Rack Units
1U
Cooling
Convection (Fanless)
Input Voltage
100-240V AC
Dimensions
19" x 1.75" x 11.75"

Key Features

  • 8 Channel Amplifier
  • Voltage 70V Version
  • OPDante and OPDAC4 Option Cards
  • DC voltage remote gain control
  • Ethernet remote control and monitoring
  • Switch mode supply, Class-D output
  • Stepped, calibrated input attenuators
  • Remote turn on/off
  • Disable all front panel controls via software
  • Temperature-sensitive variable speed fan with side-to-front airflow
  • Selectable HPF frequencies
  • Low Impedance
  • 4-stage level meters
  • Output current and temp indicators
  • Safety/Compliance: TUV, CE, FCC,RoHS
