SKU: nXE4004

Ashly nXe Series nXE4004 4-Channel 400W Power Amplifier with Programmable Outputs & Ethernet Control

Name: Ashly nXe Series nXE4004 4-Channel 400W Power Amplifier with Programmable Outputs & Ethernet Control
Brand: AVGear.com
SKU: nXE4004
Price: 2969.00 USD
Availability: InStock

$2,969.00

Items Included

Item Notes

Condition: Fully Working 5 availableⓘ

5 availableⓘ View All

Note: Each item is unique. please check individual listings for details.

Pre-Owned Guarantee 14 Day Return Window

Trade-In & SAVE Click Here To Get Started

Description

The nXe Series NXE4004 4-Channel 400W Power Amplifier with Programmable Outputs & Ethernet Control from Ashly is a Class-D switching amplifier combined with a switch mode power supply. This amplifier meets the requirements of demanding live sound and fixed installation sound systems in stadiums, arenas, performance venues, worship spaces, and convention centers. The rear panel has DIP switches for programming each channel output for either High-Z or Low-Z operation. This amplifier can be connected to a network with Ethernet control and features serial data control, aux preamp outputs, instant standby mode, preset recall, fault condition logic outputs, and optional network audio and digital audio capability, all controlled using the Protea Software Suite (not included). Read more

Features

4-Channel high-output amplifier with programmable output on each channel (High-Z or Low-Z, selected via rear panel DIP switches)
Power-saving, Energy Management System with automatic <1W sleep-mode (defeatable)
Front panel power switch and level controls (can be disabled for security)
Rear panel DIP switches per channel for selection of high pass filter, limiter, input gain, and High-Z or Low-Z speaker output configuration
Remote DC level control on each input channel
Switch mode power supply automatically detects 120 or 240VAC operation
Extensive protection circuitry and continuously variable cooling fans
Multiple independent internal power supplies provide increased channel separation and reliability
Ethernet port for control and monitoring of amplifier functions, with front panel COM activity LED
Serial data port for use with Ashly remote control devices, or optional RS-232 converter for third party controllers (not included)
Protea software allows to remotely disable all front panel controls, including the on/ off switch, for a tamper-proof installation
Real-time clock with event scheduler
Instant standby mode that can be triggered by contact closure, software control, or event scheduler for reduced power consumption
Programmable power-on delay
Preset recall via contact closure, software control, remote control, or event scheduler
Aux preamp outputs, and fault condition logic outputs
Optional Cobranet or Dante network audio and AES3 digital audio input with pass-through
Neutrik Combo XLR - 1/4" TRS jack plus Euroblock input connectors
Neutrik speakON twist locking loudspeaker connectors for security, safety, and reliability
Neutrik powerCON detachable AC mains connector
Made in USA

Business Financing Options Avaiable

View Available Financing

Features

4-Channel high-output amplifier with programmable output on each channel (High-Z or Low-Z, selected via rear panel DIP switches)
Power-saving, Energy Management System with automatic <1W sleep-mode (defeatable)
Front panel power switch and level controls (can be disabled for security)
Rear panel DIP switches per channel for selection of high pass filter, limiter, input gain, and High-Z or Low-Z speaker output configuration
Remote DC level control on each input channel
Switch mode power supply automatically detects 120 or 240VAC operation
Extensive protection circuitry and continuously variable cooling fans
Multiple independent internal power supplies provide increased channel separation and reliability
Ethernet port for control and monitoring of amplifier functions, with front panel COM activity LED
Serial data port for use with Ashly remote control devices, or optional RS-232 converter for third party controllers (not included)
Protea software allows to remotely disable all front panel controls, including the on/ off switch, for a tamper-proof installation
Real-time clock with event scheduler
Instant standby mode that can be triggered by contact closure, software control, or event scheduler for reduced power consumption
Programmable power-on delay
Preset recall via contact closure, software control, remote control, or event scheduler
Aux preamp outputs, and fault condition logic outputs
Optional Cobranet or Dante network audio and AES3 digital audio input with pass-through
Neutrik Combo XLR - 1/4" TRS jack plus Euroblock input connectors
Neutrik speakON twist locking loudspeaker connectors for security, safety, and reliability
Neutrik powerCON detachable AC mains connector
Made in USA

No products currently in stock

About the Ashly nXe Series nXE4004 4-Channel 400W Power Amplifier with Programmable Outputs & Ethernet Control

The Ashly nXe Series nXE4004 is a sophisticated four-channel network power amplifier that blends high-current output with intelligent, software-defined control for modern installed audio systems. Each channel delivers substantial power via a robust amplifier design, making it suitable for driving a wide range of loudspeaker loads, from low-impedance high-fidelity speakers to 70V/100V distributed lines. A defining feature of the nXE4004 is its programmable output configuration, allowing each channel to be independently software-configured for specific operating modes, voltage taps, and processing parameters. This programmability eliminates the need for physical switches and jumpers, enabling complete system setup and adjustments to be made remotely via its Ethernet control interface.

Integrated digital signal processing is central to the amplifier's functionality, providing per-channel EQ, delay, crossover filters, and compressor/limiters. This onboard DSP allows system integrators to perform precise acoustic tuning, speaker optimization, and protective limiting directly within the amplifier, often reducing or eliminating the need for external processors. The Ethernet port facilitates network integration for control, monitoring, and audio transport, supporting Ashly's control protocols and, with optional cards, audio networking standards like Dante. Real-time monitoring of parameters such as output level, clipping, impedance, and temperature is accessible from a central computer, providing valuable system diagnostics.

Housed in a 2U rack-mountable chassis designed for optimal thermal management, the nXE4004 is built for reliable 24/7 operation in demanding commercial environments. Its combination of high power, programmable outputs, extensive DSP, and network control makes it a highly flexible and intelligent amplification platform. The Ashly nXE4004 is engineered for system architects who require a future-proof, software-configurable amplifier that can adapt to evolving system needs and provide centralized management within a networked audio ecosystem.

Key Features

4-Channel high-output amplifier with programmable output on each channel (High-Z or Low-Z, selected via rear panel DIP switches)
Power-saving, Energy Management System with automatic <1W sleep-mode (defeatable)
Front panel power switch and level controls (can be disabled for security)
Rear panel DIP switches per channel for selection of high pass filter, limiter, input gain, and High-Z or Low-Z speaker output configuration
Remote DC level control on each input channel
Switch mode power supply automatically detects 120 or 240VAC operation
Extensive protection circuitry and continuously variable cooling fans
Multiple independent internal power supplies provide increased channel separation and reliability
Ethernet port for control and monitoring of amplifier functions, with front panel COM activity LED
Serial data port for use with Ashly remote control devices, or optional RS-232 converter for third party controllers (not included)
Protea software allows to remotely disable all front panel controls, including the on/ off switch, for a tamper-proof installation
Real-time clock with event scheduler
Instant standby mode that can be triggered by contact closure, software control, or event scheduler for reduced power consumption
Programmable power-on delay
Preset recall via contact closure, software control, remote control, or event scheduler
Aux preamp outputs, and fault condition logic outputs
Optional Cobranet or Dante network audio and AES3 digital audio input with pass-through
Neutrik Combo XLR - 1/4" TRS jack plus Euroblock input connectors
Neutrik speakON twist locking loudspeaker connectors for security, safety, and reliability
Neutrik powerCON detachable AC mains connector
Made in USA
