Description

The NXE Series 2-Channel Networkable Multi-Mode Power Amplifier from Ashly comes pre-installed with OPDAC4 internal 4-Channel DAC with selectable HPF and OPDante Dante Network Audio Interface cards. The OPDante card enables access to digital audio networks at low latencies (83.3 μs) over fast Ethernet. It can be installed in the rear card slot of NXE series amplifiers. Signal can be routed from other Dante enabled devices by simply connecting a Cat5e or Cat6 cable to the card's primary or secondary (redundant) Ethernet ports. The amplifier is capable of driving 2 Ohms loads at full power and offers a maximum rated output power of 800W per channel at Low Z, 70V, and 100V modes. In addition, the amplifier is suitable for use in performance venues, stadiums, arenas, convention centers as well as schools, store fronts, and places of worship. The multi-mode amplifier features an automatic but defeatable sleep mode consuming <1W, and instant standby mode controlled by contact closure or software. A switch mode power supply can auto-detect 120 or 240 VAC mains, and a Neutrik powerCON is used for the AC cord. Each channel features a selectable output mode of Low Z, 70V, or 100V, an 80 Hz high-pass filter, input limiter, and input gain settings of 26 dB, 32 dB, 38 dB, or 1.4V. Each channel comes with a remote DC level control. The amplifier comes with Neutrik XLR/TRS combo jack and Euroblock input connectors and Neutrik speakON output connectors. The unit features a front panel power switch and level controls that can be disabled. The LEDs indicate Protect, Sleep, Disabled, Com, and Bridge mode status, as well as Temperature, Output Current, Output Signal, and Clipping/Mute status per channel. In addition, the power amplifier features an Ethernet control with a real-time clock for event scheduling. Read more

Features

Ethernet control using Protea NE software
Serial data control by Ashly programmable remotes or third party controllers
Aux preamp outputs, instant standby mode, preset recall, fault condition logic outputs, and optional CobraNet or AES3 digital audio capability
Real-time clock with event scheduler
Assign automatic execution of selected functions and tasks
Event scheduler is programmed using PneS software and stored in the amplifier
Ashly remote control via iPad app for custom design of secure wireless control over a network
Features a switch-mode power supply that automatically detects 120 or 240 VAC operation
Selectable outputs on each channel allow you to choose the desired output mode
Set the DIP-switch configuration for low impedance (2, 4, and 8 Ohms), or constant voltage (70V or 100V)
Ashly EMS (Energy Management System) provides an automatic sleep-mode drawing less than 1W (defeatable)
Multiple internal power supplies provide increased channel separation and reliability
Selectable 80 Hz hi-pass filter, limiter, and input gain per channel via rear panel
Remote DC level control per channel
Extensive protection circuitry and continuously variable cooling fans
Ethernet port for software control and monitoring of amplifier functions with front panel COM activity LED
Serial data port available for optional Ashly WR-5 and RD-8C programmable remote controls (optional RS-232 converter INA-1 available for third party controllers)
Instant standby mode results in 30% reduction in idle power consumption that is triggered by contact closure, software control, or event scheduler
Preset recall via contact closure, software control, remote control, or event scheduler
Programmable power-on delay
Aux preamp line outputs for driving other amplifiers
Assignable fault condition logic outputs
Neutrik Combo XLR - 1/4" TRS jack plus Euroblock input connectors
Neutrik speakON twist locking loudspeaker connectors
Neutrik powerCON detachable AC mains connector

Business Financing Options Avaiable

View Available Financing

Features

Ethernet control using Protea NE software
Serial data control by Ashly programmable remotes or third party controllers
Aux preamp outputs, instant standby mode, preset recall, fault condition logic outputs, and optional CobraNet or AES3 digital audio capability
Real-time clock with event scheduler
Assign automatic execution of selected functions and tasks
Event scheduler is programmed using PneS software and stored in the amplifier
Ashly remote control via iPad app for custom design of secure wireless control over a network
Features a switch-mode power supply that automatically detects 120 or 240 VAC operation
Selectable outputs on each channel allow you to choose the desired output mode
Set the DIP-switch configuration for low impedance (2, 4, and 8 Ohms), or constant voltage (70V or 100V)
Ashly EMS (Energy Management System) provides an automatic sleep-mode drawing less than 1W (defeatable)
Multiple internal power supplies provide increased channel separation and reliability
Selectable 80 Hz hi-pass filter, limiter, and input gain per channel via rear panel
Remote DC level control per channel
Extensive protection circuitry and continuously variable cooling fans
Ethernet port for software control and monitoring of amplifier functions with front panel COM activity LED
Serial data port available for optional Ashly WR-5 and RD-8C programmable remote controls (optional RS-232 converter INA-1 available for third party controllers)
Instant standby mode results in 30% reduction in idle power consumption that is triggered by contact closure, software control, or event scheduler
Preset recall via contact closure, software control, remote control, or event scheduler
Programmable power-on delay
Aux preamp line outputs for driving other amplifiers
Assignable fault condition logic outputs
Neutrik Combo XLR - 1/4" TRS jack plus Euroblock input connectors
Neutrik speakON twist locking loudspeaker connectors
Neutrik powerCON detachable AC mains connector

No products currently in stock

About the Ashly nXE8002BD 2-Channel Networkable Multi-Mode Power Amplifier with OPDAC4 & OPDante Cards

The Ashly nXE8002BD is a professional 2-channel networkable multi-mode power amplifier designed for demanding installed sound applications requiring high-output amplification, advanced network control, and seamless Dante® digital audio integration. Based on the Ashly nXe Series, this model is factory-equipped with both the OPDante® network audio interface and OPDAC4 digital-to-analog converter card, enabling direct integration into Dante-enabled audio networks while maintaining exceptional audio performance and flexible loudspeaker system configuration. It is ideally suited for stadiums, theaters, houses of worship, convention centers, educational facilities, and commercial AV installations.

Powered by efficient Class-D amplifier technology with a switch-mode power supply, the nXE8002BD delivers 800 watts per channel and supports Low-Z, 70V, and 100V loudspeaker systems through programmable output configuration. Built-in Ethernet networking allows complete remote configuration, monitoring, preset management, scheduling, and diagnostics using Ashly Protea™ software. The amplifier also incorporates programmable DSP functions including input gain selection, high-pass filtering, limiting, and remote level control to optimize system performance and loudspeaker protection.

The factory-installed OPDante module enables low-latency Dante digital audio transport over standard Gigabit Ethernet networks with redundant network ports for increased system reliability. The accompanying OPDAC4 module provides high-quality digital-to-analog conversion for Dante audio, allowing direct integration into modern networked audio infrastructures without requiring external converters. Additional installation features include event scheduling, programmable power sequencing, preset recall, auxiliary preamp outputs, logic fault outputs, and serial remote control support.

Housed in a rugged 2 RU rackmount chassis, the nXE8002BD is engineered for continuous operation in mission-critical environments. Multiple internal power supplies improve channel separation and reliability, while temperature-controlled variable-speed cooling and comprehensive protection circuitry ensure dependable long-term performance. Its combination of high-output amplification, Dante networking, DSP flexibility, and enterprise-grade control capabilities makes it an excellent choice for professional installed sound systems.

Key Features

Ethernet control using Protea NE software
Serial data control by Ashly programmable remotes or third party controllers
Aux preamp outputs, instant standby mode, preset recall, fault condition logic outputs, and optional CobraNet or AES3 digital audio capability
Real-time clock with event scheduler
Assign automatic execution of selected functions and tasks
Event scheduler is programmed using PneS software and stored in the amplifier
Ashly remote control via iPad app for custom design of secure wireless control over a network
Features a switch-mode power supply that automatically detects 120 or 240 VAC operation
Selectable outputs on each channel allow you to choose the desired output mode
Set the DIP-switch configuration for low impedance (2, 4, and 8 Ohms), or constant voltage (70V or 100V)
Ashly EMS (Energy Management System) provides an automatic sleep-mode drawing less than 1W (defeatable)
Multiple internal power supplies provide increased channel separation and reliability
Selectable 80 Hz hi-pass filter, limiter, and input gain per channel via rear panel
Remote DC level control per channel
Extensive protection circuitry and continuously variable cooling fans
Ethernet port for software control and monitoring of amplifier functions with front panel COM activity LED
Serial data port available for optional Ashly WR-5 and RD-8C programmable remote controls (optional RS-232 converter INA-1 available for third party controllers)
Instant standby mode results in 30% reduction in idle power consumption that is triggered by contact closure, software control, or event scheduler
Preset recall via contact closure, software control, remote control, or event scheduler
Programmable power-on delay
Aux preamp line outputs for driving other amplifiers
Assignable fault condition logic outputs
Neutrik Combo XLR - 1/4" TRS jack plus Euroblock input connectors
Neutrik speakON twist locking loudspeaker connectors
Neutrik powerCON detachable AC mains connector

Already own this item and want to sell it?

Click here to sell your item

Ashly nXE8002BD 2-Channel Networkable Multi-Mode Power Amplifier with OPDAC4 & OPDante Cards Specs

Amplifier Performance

Amplifier Channels

Amplifier Class

Class-D

Power Output @ 2 Ω

800 W per Channel

Power Output @ 4 Ω

800 W per Channel

Power Output @ 8 Ω

800 W per Channel

Bridged Power @ 4 Ω

1,600 W

70 V Output

800 W per Channel

100 V Output

800 W per Channel

Frequency Response

20 Hz – 20 kHz

THD+N

<0.5%

Signal-to-Noise Ratio

>100 dB

Damping Factor

>250

Digital Audio & DSP

Digital Audio Interface

OPDante® (Factory Installed)

DAC Module

OPDAC4 (Factory Installed)

Network Audio

Dante®

Input Gain

Selectable 26 dB, 32 dB, 38 dB, 1.4 V

High-Pass Filter

80 Hz, 2nd Order

Limiter

Programmable Per Channel

Output Mode

Low-Z / 70 V / 100 V Selectable

Network & Control

Network Interface

Dual RJ45 Gigabit Ethernet (Primary/Secondary)

Remote Control

Ashly Protea™ Software

Event Scheduler

Yes

Preset Recall

Yes

Remote DC Level Control

Yes

Logic Outputs

Fault Status Outputs

Audio Connections

Analog Inputs

Neutrik Combo XLR/TRS, Euroblock

Speaker Outputs

Neutrik speakON®

Aux Outputs

Balanced Line Outputs

Electrical

Operating Voltage

100–240 V AC, 50/60 Hz (Auto-Sensing)

Power Connector

Neutrik powerCON®

Cooling

Variable-Speed Forced-Air

Protection

Thermal, Short Circuit, DC Offset, Over-Current, Power Supply Fault

Construction

Rack Height

2 RU

Chassis Material

Steel

Finish

Black Powder-Coated

Dimensions

Width

19.00 in

Height

3.50 in

Depth

16.84 in

Weight

Net Weight

22.2 lb

Key Features

Ethernet control using Protea NE software
Serial data control by Ashly programmable remotes or third party controllers
Aux preamp outputs, instant standby mode, preset recall, fault condition logic outputs, and optional CobraNet or AES3 digital audio capability
Real-time clock with event scheduler
Assign automatic execution of selected functions and tasks
Event scheduler is programmed using PneS software and stored in the amplifier
Ashly remote control via iPad app for custom design of secure wireless control over a network
Features a switch-mode power supply that automatically detects 120 or 240 VAC operation
Selectable outputs on each channel allow you to choose the desired output mode
Set the DIP-switch configuration for low impedance (2, 4, and 8 Ohms), or constant voltage (70V or 100V)
Ashly EMS (Energy Management System) provides an automatic sleep-mode drawing less than 1W (defeatable)
Multiple internal power supplies provide increased channel separation and reliability
Selectable 80 Hz hi-pass filter, limiter, and input gain per channel via rear panel
Remote DC level control per channel
Extensive protection circuitry and continuously variable cooling fans
Ethernet port for software control and monitoring of amplifier functions with front panel COM activity LED
Serial data port available for optional Ashly WR-5 and RD-8C programmable remote controls (optional RS-232 converter INA-1 available for third party controllers)
Instant standby mode results in 30% reduction in idle power consumption that is triggered by contact closure, software control, or event scheduler
Preset recall via contact closure, software control, remote control, or event scheduler
Programmable power-on delay
Aux preamp line outputs for driving other amplifiers
Assignable fault condition logic outputs
Neutrik Combo XLR - 1/4" TRS jack plus Euroblock input connectors
Neutrik speakON twist locking loudspeaker connectors
Neutrik powerCON detachable AC mains connector
