QSC AD-C800RG 8" Ceiling Mount Loudspeaker

$39.99

Items Included

QSC AD-C800RG 8" Ceiling Mount Loudspeaker

Item Notes

Condition: Out of stock
Once stock replenishes, inventory will display below.
Pricing
Sold out
Pre-Owned Guarantee 14 Day Return Window

Description

The QSC AD-C820R System includes an AD-C820 speaker baffle, AD-C800BB backcan assembly and AD-C800RG round grille. The AD-C820 ceiling speaker is designed for music playback, public address and distributed audio in applications that require high output from a ceiling mounted loudspeaker. It uses custom designed transducers and crossover networks, in combination with an acoustically optimized enclosure (AD-C800BB). The 8" woofer is equipped with a treated paper cone on a steel frame. In the optimized enclosure the usable low frequency of the system extends to 52 Hz. The 1.4" compression driver fires through the center of the woofer and is acoustically mated to the woofer for a smooth transition at crossover. High-current, low tolerance network components provide smooth full-range, passive performance. The included 70/100 V, custom designed transformer is optimized for low line loss as well as accurate and transparent acoustic performance. Read more

Features

  • 8-inch ceiling-mounted loudspeaker for distributed audio systems
  • Designed for high-quality foreground and background sound
  • Wide frequency response for clear voice and music reproduction
  • Low-profile grille design for discreet ceiling integration
  • Rugged construction suitable for commercial and public spaces

Business Financing Options Avaiable

The QSC AD-C820R System includes an AD-C820 speaker baffle, AD-C800BB backcan assembly and AD-C800RG round grille. The AD-C820 ceiling speaker is designed for music playback, public address and distributed audio in applications that require high output from a ceiling mounted loudspeaker. It uses custom designed transducers and crossover networks, in combination with an acoustically optimized enclosure (AD-C800BB). The 8" woofer is equipped with a treated paper cone on a steel frame. In the optimized enclosure the usable low frequency of the system extends to 52 Hz. The 1.4" compression driver fires through the center of the woofer and is acoustically mated to the woofer for a smooth transition at crossover. High-current, low tolerance network components provide smooth full-range, passive performance. The included 70/100 V, custom designed transformer is optimized for low line loss as well as accurate and transparent acoustic performance. Read more

Features

  • 8-inch ceiling-mounted loudspeaker for distributed audio systems
  • Designed for high-quality foreground and background sound
  • Wide frequency response for clear voice and music reproduction
  • Low-profile grille design for discreet ceiling integration
  • Rugged construction suitable for commercial and public spaces

About the QSC AD-C800RG 8" Ceiling Mount Loudspeaker

The QSC AD-C800RG is a professional 8-inch coaxial ceiling loudspeaker engineered for distributed audio systems in commercial spaces. It delivers clear, intelligible sound for background music, paging, and audio reinforcement in environments such as retail stores, hotels, restaurants, and corporate offices. The coaxial driver design aligns the high-frequency component within the low-frequency cone, ensuring precise acoustic coherence and a wide, consistent dispersion pattern for even room coverage.

A standout feature is its Rigid-Grill (RG) construction, featuring a durable, non-removable steel grille that withstands impact and cleaning in high-traffic areas. The paintable trim ring and low-profile design allow the speaker to blend seamlessly into standard ceiling tiles. The moisture-resistant composite enclosure provides durability for indoor use, making it a reliable choice for various installation environments.

Installation is streamlined through a tool-free mounting system with adjustable tension clamps for secure placement in T-bar ceilings. The integrated multi-tap transformer offers flexible connectivity options, supporting direct 8-ohm low-impedance operation or 70V/100V constant-voltage systems with selectable power taps. The AD-C800RG combines robust build quality, acoustic performance, and installer-friendly features for efficient integration into professional commercial audio systems.

Key Features

  • 8-inch ceiling-mounted loudspeaker for distributed audio systems
  • Designed for high-quality foreground and background sound
  • Wide frequency response for clear voice and music reproduction
  • Low-profile grille design for discreet ceiling integration
  • Rugged construction suitable for commercial and public spaces

QSC AD-C800RG 8" Ceiling Mount Loudspeaker Specs

Transducer & Acoustics
Driver Type
8-inch coaxial
Frequency Response
62 Hz - 20 kHz (±3 dB)
Sensitivity
89 dB (1W/1m)
Maximum SPL
111 dB peak
Dispersion
130° conical
Amplification & Compatibility
Impedance Options
8 ohms, 70V, 100V
Transformer Taps
70V: 60W, 30W, 15W, 7.5W; 100V: 60W, 30W, 15W; 8Ω
Power Handling (RMS)
60 Watts
Enclosure & Installation
Enclosure Material
Moisture-resistant composite
Grille
Integrated rigid steel
Mounting
Tool-free drop-in for T-bar ceilings
Trim Ring
Paintable
Dimensions
318 mm diameter, 226 mm depth
Cutout Diameter
260 mm

Key Features

  • 8-inch ceiling-mounted loudspeaker for distributed audio systems
  • Designed for high-quality foreground and background sound
  • Wide frequency response for clear voice and music reproduction
  • Low-profile grille design for discreet ceiling integration
  • Rugged construction suitable for commercial and public spaces
