ETC

ETC CL-EOS Ti Enhanced 24,576 Ch

$0.00

The phrase "ETC CL-EOS Ti Enhanced 24,576 Ch" refers to a lighting control console configuration from Electronic Theatre Controls (ETC). The CL-EOS Ti is the "Enhanced" version of the Eos Titanium, a flagship console in the Eos family, and the 24,576 Ch specifies its maximum output capacity.

View Product Features

  • utputs and channels: The primary feature of this configuration is its ability to support up to 24,576 outputs and 32,768 control channels. This makes it suitable for large-scale theatrical and live events with numerous conventional, LED, and moving lights.
  • Processing: It handles all 24,576 outputs without co-processing, ensuring smooth operation and control.
  • Playback control: The console features a dedicated motorized master playback fader pair and 10 configurable motorized faders with 100 pages of control.
  • Display interfaces: The "Enhanced" version includes two built-in articulating 18.5" multi-touch LCD displays and a dedicated 9" multi-touch encoder display. It also supports up to three external monitors via Display Port connectors.
  • Control surface: The console's surface features backlit buttons, a backlit keyboard, and multiple USB ports for connectivity.
Out of Stock
0 in stock

Once stock replenishes, inventory will display below.

Already own this item and want to sell it?

About the ETC CL-EOS Ti Enhanced 24,576 Ch

The ETC Eos Ti Enhanced is a flagship-tier, large-format lighting console that represents the pinnacle of the Eos Family software platform, engineered for the most demanding and complex lighting designs in theatre, opera, broadcast, and large-scale live events. Its processing architecture is built to manage an expansive 24,576 DMX control channels, facilitating the programming and real-time operation of thousands of intelligent fixtures, conventional dimmers, and networked devices across hundreds of universes. The console's hardware is designed around an ergonomic, user-centric layout, featuring a blend of high-resolution multi-touch screens, dedicated mechanical playback faders, a vast array of customizable macro and direct-select keys, and the signature command wing with its precise trackball and encoder wheels for intuitive parameter manipulation. This physical interface provides tactile, immediate control that is essential for live performance cueing and fine adjustments under pressure.

At the heart of the system is the latest version of Eos software, renowned for its deep feature set, logical workflow, and powerful show file compatibility. It offers advanced tools for managing moving lights, pixel mapping, and complex effects, alongside robust timecode and show control capabilities for synchronization with audio and video systems. The console supports high-density DMX output via multiple networked pathways, including sACN and Art-Net, and integrates seamlessly with ETC's ecosystem of networking hardware and visualization software. Redundant components, such as dual hot-swappable power supplies and network ports, are standard, ensuring maximum uptime and reliability for mission-critical productions where a console failure is not an option.

The Ti Enhanced is more than a control surface; it is a complete, integrated system designed for collaboration and scalability. It often supports multi-user operation, allowing a programmer and an operator to work on different tasks simultaneously. Its construction is rugged for touring, yet its interface remains refined and accessible. By combining immense processing power with the industry's most trusted theatrical control software in a purpose-built, reliable hardware package, the Eos Ti Enhanced establishes itself as the console of choice for productions where creative ambition, technical scale, and absolute reliability must converge without compromise.

Key Features

  • utputs and channels: The primary feature of this configuration is its ability to support up to 24,576 outputs and 32,768 control channels. This makes it suitable for large-scale theatrical and live events with numerous conventional, LED, and moving lights.
  • Processing: It handles all 24,576 outputs without co-processing, ensuring smooth operation and control.
  • Playback control: The console features a dedicated motorized master playback fader pair and 10 configurable motorized faders with 100 pages of control.
  • Display interfaces: The "Enhanced" version includes two built-in articulating 18.5" multi-touch LCD displays and a dedicated 9" multi-touch encoder display. It also supports up to three external monitors via Display Port connectors.
  • Control surface: The console's surface features backlit buttons, a backlit keyboard, and multiple USB ports for connectivity.

ETC CL-EOS Ti Enhanced 24,576 Ch Specs

Processing & Capacity
Maximum DMX Channels
24,576
Maximum DMX Universes
512
Internal Cue Capacity
Extensive, Limited by Storage
Multi-User Operation
Yes, Multi-Console Network
Control Surface
Touchscreen Displays
3 x High-Resolution
Mechanical Playback Faders
60 (Motorized)
Encoder Wheels
3 with LCD Displays
Customizable Hard Keys
Over 100
Output & Connectivity
Network Protocols
sACN, Art-Net, ETCNet3
Ethernet Ports
4 x 1Gb with PoE+
DMX Ports
4 x 5-pin XLR (Direct Output)
Redundant Power Supplies
Dual, Hot-Swappable
Software & Integration
Software Platform
Eos Family (Enhanced Version)
Visualization Integration
Augment3d, Capture
Show Control
MIDI, OSC, Timecode LTC/MTC
Backup/Redundancy
Full Console Mirroring
Physical Build
Form Factor
Large-Format Console Desk
Construction
Steel Frame, Aluminum Surfaces
Weight
Approx. 250 lbs (113 kg)
Dimensions
Custom, Large Footprint

Key Features

  • utputs and channels: The primary feature of this configuration is its ability to support up to 24,576 outputs and 32,768 control channels. This makes it suitable for large-scale theatrical and live events with numerous conventional, LED, and moving lights.
  • Processing: It handles all 24,576 outputs without co-processing, ensuring smooth operation and control.
  • Playback control: The console features a dedicated motorized master playback fader pair and 10 configurable motorized faders with 100 pages of control.
  • Display interfaces: The "Enhanced" version includes two built-in articulating 18.5" multi-touch LCD displays and a dedicated 9" multi-touch encoder display. It also supports up to three external monitors via Display Port connectors.
  • Control surface: The console's surface features backlit buttons, a backlit keyboard, and multiple USB ports for connectivity.
