Electro-Voice ZXA1 8" Full Range Portable Loudspeaker

$0.00

Items Included

Electro-Voice ZXA1 8" Full Range Portable Loudspeaker

Item Notes

Condition: Out of stock
Once stock replenishes, inventory will display below.
Pricing
Sold out
Pre-Owned Guarantee 14 Day Return Window

Description

Experience powerful, dynamic sound with the Electro Voice ZXA1 8" 2 Way Powered Speaker! Ideal for fitness centers, it boasts a crisp, impactful sound. Push your workout to new heights with remarkable audio quality! The Electro-Voice ZXA1 is powered by an 800 watt amplifier module derived from EV’s world-tour-class Tour Grade series amplifiers with audio quality and reliability proven at the very highest levels. Read more

Features

  • Integrated 800 watt power amplifier
  • Bi-amplified design with transducer protection
  • EV8L 8” high-output LF transducer
  • DH2005 1” exit true compression driver
  • 90° x 50° coverage pattern

Business Financing Options Avaiable

Experience powerful, dynamic sound with the Electro Voice ZXA1 8" 2 Way Powered Speaker! Ideal for fitness centers, it boasts a crisp, impactful sound. Push your workout to new heights with remarkable audio quality! The Electro-Voice ZXA1 is powered by an 800 watt amplifier module derived from EV’s world-tour-class Tour Grade series amplifiers with audio quality and reliability proven at the very highest levels. Read more

Features

  • Integrated 800 watt power amplifier
  • Bi-amplified design with transducer protection
  • EV8L 8” high-output LF transducer
  • DH2005 1” exit true compression driver
  • 90° x 50° coverage pattern

About the Electro-Voice ZXA1 8" Full Range Portable Loudspeaker

The Electro-Voice ZXA1 8" Full Range Portable Loudspeaker is a compact, two-way powered speaker system that delivers professional-grade audio reinforcement in a highly portable and lightweight package. Designed to cater to musicians, mobile DJs, presenters, and corporate events, the ZXA1 integrates an 800-watt Class D amplifier directly into the enclosure. This self-contained design eliminates the need for external amplifiers, simplifying setup, reducing cable clutter, and making the entire system incredibly easy to transport and deploy in small to medium-sized venues. Its small physical footprint ensures it can fit discreetly into various locations.

The loudspeaker utilizes an 8-inch high-excursion woofer coupled with a premium 1-inch titanium diaphragm compression driver. This combination is managed by an internal passive crossover and advanced protection circuitry, which work together to produce a smooth frequency response and clear, high-fidelity sound. The speaker's design incorporates a precisely engineered coverage pattern (typically 90°x90° depending on the specific horn variant), ensuring broad and consistent sound dispersion that minimizes dead spots across the audience area, enhancing vocal clarity and overall audio quality.

Constructed from a durable, high-impact composite material, the ZXA1 chassis is built to withstand the rigors of frequent transport and stage use. Its remarkably light weight (under 20 lbs) makes single-person handling and setup effortless. Integrated mounting options, including a pole mount socket for stand placement and an angled rear panel, allow the speaker to double as an effective stage monitor or floor wedge when placed horizontally. The ZXA1 is a versatile and reliable solution for professionals demanding performance, durability, and convenience.

Key Features

  • Integrated 800 watt power amplifier
  • Bi-amplified design with transducer protection
  • EV8L 8” high-output LF transducer
  • DH2005 1” exit true compression driver
  • 90° x 50° coverage pattern

Electro-Voice ZXA1 8" Full Range Portable Loudspeaker Specs

Physical Characteristics
Enclosure Material
High-impact composite polypropylene
Finish
Black texture
Dimensions (H x W x D)
457 mm x 282 mm x 269 mm (18.0" x 11.1" x 10.6")
Weight
8.6 kg (19 lbs)
Grille Material
Powder-coated 18GA steel
Mounting
Integrated 35mm pole mount socket; Integrated handle
Acoustical
Frequency Response (-3 dB)
60 Hz to 20 kHz
Frequency Range (-10 dB)
48 Hz to 20 kHz
Maximum SPL (Peak)
123 dB
Nominal Coverage (H x V)
90° x 90° (typical for ZXA1-90 model)
Crossover Frequency
1.8 kHz
Electrical & Amplifier
Amplifier Type
Class D
Amplifier Power (Continuous)
800 Watts
Power Consumption
600 W (current draw at 1/8 max output)
AC Power Input
120 VAC, 50-60 Hz or 230 VAC, 50-60 Hz (selectable)
Connections & Controls
Input Connectors
1 x XLR/TRS combo jack (Line/Mic input); 1 x XLR link output
Output Connector
1 x XLR link output
Controls
Gain knob; Mic/Line switch; Hi Pass Filter switch; Power switch
Indicator LEDs
Power (blue); Limit (red)

Key Features

  • Integrated 800 watt power amplifier
  • Bi-amplified design with transducer protection
  • EV8L 8” high-output LF transducer
  • DH2005 1” exit true compression driver
  • 90° x 50° coverage pattern

FAQs about Electro-Voice ZXA1 8" Full Range Portable Loudspeaker
