SKU: 2119-308

Meyer Sound ULTRA-X40 Wide Coverage Loudspeaker

$4,699.99 - $6,900.00

Items Included

Item Notes

Condition: Fully Working 5 availableⓘ
5 availableⓘ View All
Note: Each item is unique. please check individual listings for details.
Price
Add to cart
Pre-Owned Guarantee 14 Day Return Window
Trade-In & SAVE Click Here To Get Started

Description

The Meyer ULTRA-X40 packs the technology breakthroughs of Meyer Sound's flagship line arrays into a compact, self-powered loudspeaker. Its concentric driver configuration delivers exceptional fidelity with high power and low distortion, while a rotatable 110° x 50° Constant-Q horn supplies wide, uniform coverage. Read more

Features

  • 1950W Class D amplifier delivers full-range sound from 56Hz–19kHz
  • 127dB linear peak SPL enables high peak power with near-imperceptible distortion
  • Innovative concentric-driver configuration with dual 8-inch cone woofers and a 3-inch tweeter
  • Rotatable 110° x 50° Constant-Q horn supplies wide, uniform coverage
  • Simple self-powered design — no amp rack or long cable runs necessary
  • Onboard processing with crossover, correction filters, and driver protection circuitry
  • IntelligentAC automatically eliminates the need for an external power conditioner
  • Permits you to monitor in real time with RMS remote monitoring
  • Tour-tough trapezoidal, multi-ply birch enclosure with a textured black finish
  • Rugged powder coated, round-perforated steel grille
  • Includes 11 integrated M8 threaded points and a 35mm pole mount receptacle with M20 threads
  • Tailor-made for theme parks, worship venues, theater shows, lecture halls, and large-scale concerts

Business Financing Options Avaiable

View Available Financing

The Meyer ULTRA-X40 packs the technology breakthroughs of Meyer Sound's flagship line arrays into a compact, self-powered loudspeaker. Its concentric driver configuration delivers exceptional fidelity with high power and low distortion, while a rotatable 110° x 50° Constant-Q horn supplies wide, uniform coverage. Read more

Features

  • 1950W Class D amplifier delivers full-range sound from 56Hz–19kHz
  • 127dB linear peak SPL enables high peak power with near-imperceptible distortion
  • Innovative concentric-driver configuration with dual 8-inch cone woofers and a 3-inch tweeter
  • Rotatable 110° x 50° Constant-Q horn supplies wide, uniform coverage
  • Simple self-powered design — no amp rack or long cable runs necessary
  • Onboard processing with crossover, correction filters, and driver protection circuitry
  • IntelligentAC automatically eliminates the need for an external power conditioner
  • Permits you to monitor in real time with RMS remote monitoring
  • Tour-tough trapezoidal, multi-ply birch enclosure with a textured black finish
  • Rugged powder coated, round-perforated steel grille
  • Includes 11 integrated M8 threaded points and a 35mm pole mount receptacle with M20 threads
  • Tailor-made for theme parks, worship venues, theater shows, lecture halls, and large-scale concerts

Recommended Accessories

    No products currently in stock

Frequently Purchased Together

    No products currently in stock

About the Meyer Sound ULTRA-X40 Wide Coverage Loudspeaker

The Meyer ULTRA-X40 brings the technology breakthroughs of Meyer Sound's flagship line arrays into a compact, self-powered point source loudspeaker. A concentric configuration pairs dual 8-inch neodymium cone woofers with a single 3-inch diaphragm compression driver for exceptional fidelity with high power and low distortion. Its rotatable 110° x 50° Constant-Q horn supplies wide, uniform coverage that stays consistent in a horizontal or vertical orientation, with directional control down to 400 Hz.

Power comes from a new 3-channel Class D amplifier that produces 1950W of total peak output power and draws only about 1.3A at 230V AC. Onboard processing handles the crossover, phase and frequency response correction, and driver protection, while IntelligentAC removes the need for an external power conditioner. Setup stays simple with no amp rack or long cable runs, and 11 M8 rigging points plus a 35mm pole mount receptacle open up a wide variety of mounting options. Optional RMS remote monitoring lets you watch loudspeaker parameters from a Windows or Mac computer.

Every ULTRA-X40 from AVGear is inspected, tested, and graded for function and cosmetics, so you know the condition before you buy.

Key Features

  • 1950W Class D amplifier delivers full-range sound from 56Hz–19kHz
  • 127dB linear peak SPL enables high peak power with near-imperceptible distortion
  • Innovative concentric-driver configuration with dual 8-inch cone woofers and a 3-inch tweeter
  • Rotatable 110° x 50° Constant-Q horn supplies wide, uniform coverage
  • Simple self-powered design — no amp rack or long cable runs necessary
  • Onboard processing with crossover, correction filters, and driver protection circuitry
  • IntelligentAC automatically eliminates the need for an external power conditioner
  • Permits you to monitor in real time with RMS remote monitoring
  • Tour-tough trapezoidal, multi-ply birch enclosure with a textured black finish
  • Rugged powder coated, round-perforated steel grille
  • Includes 11 integrated M8 threaded points and a 35mm pole mount receptacle with M20 threads
  • Tailor-made for theme parks, worship venues, theater shows, lecture halls, and large-scale concerts

Already own this item and want to sell it?

Click here to sell your item

Meyer Sound ULTRA-X40 Wide Coverage Loudspeaker Specs

Powered
Yes
Power Configuration
Tri-amped
LF Driver Size
2 x 8" Cone Woofers
HF Driver Size
1 x 3" Compression Driver
Total Power
1950W Class D
Inputs
1 x XLR
Outputs
1 x XLR
Frequency Range
55Hz to 19.5kHz
Frequency Response
56Hz to 19kHz (±4dB)
Maximum Peak SPL
138 dB SPL
Horizontal Coverage Angle
100°
Vertical Coverage Angle
50°
Enclosure Material
Multi-ply Birch, Textured Black Finish
Mounting Options
1 x 35mm Pole Mount, 11 x M8 Threaded Mount Points (fly)
Power Source
Locking Power Input, Output (cable included)

Key Features

  • 1950W Class D amplifier delivers full-range sound from 56Hz–19kHz
  • 127dB linear peak SPL enables high peak power with near-imperceptible distortion
  • Innovative concentric-driver configuration with dual 8-inch cone woofers and a 3-inch tweeter
  • Rotatable 110° x 50° Constant-Q horn supplies wide, uniform coverage
  • Simple self-powered design — no amp rack or long cable runs necessary
  • Onboard processing with crossover, correction filters, and driver protection circuitry
  • IntelligentAC automatically eliminates the need for an external power conditioner
  • Permits you to monitor in real time with RMS remote monitoring
  • Tour-tough trapezoidal, multi-ply birch enclosure with a textured black finish
  • Rugged powder coated, round-perforated steel grille
  • Includes 11 integrated M8 threaded points and a 35mm pole mount receptacle with M20 threads
  • Tailor-made for theme parks, worship venues, theater shows, lecture halls, and large-scale concerts

Already own this item and want to sell it?

Click here to sell your item

FAQs about Meyer Sound ULTRA-X40 Wide Coverage Loudspeaker

What is M-noise, and why does Meyer use it instead of pink noise for SPL ratings?

M-noise is a music-based test signal Meyer Sound created to measure real-world loudspeaker output. Unlike pink noise, its peak level changes across the frequency band the way music does, so the rating reflects performance with actual program material. Meyer rates the ULTRA-X40 at 132.5 dB linear peak SPL using M-noise.

Does the ULTRA-X40 need an external processor like Galileo GALAXY?

No. The ULTRA-X40 has built-in DSP that handles the crossover, correction filters, and driver protection, so a single speaker runs without any external processor. For larger multi-speaker systems, Meyer's Galileo GALAXY platform can add matrix routing and alignment, but it is optional.

Are mounting brackets included with the ULTRA-X40, or sold separately?

The cabinet has 11 built-in M8 rigging points and a 35mm pole mount receptacle, but brackets and yokes are sold separately. Options include the MUB-X40 U-bracket, the MYA-X40 yoke, an adjustable pole kit, and cluster plates for grouping multiple cabinets.

Does the ULTRA-X40 have an onboard volume control?

No. The ULTRA-X40 does not have a volume knob on the cabinet. You set the level at the mixer or processor feeding its XLR input, which keeps gain staging consistent across multiple speakers.

Is the ULTRA-X40 weather resistant for outdoor use?

A weather-protected version is available as a factory option for covered outdoor use, along with custom color finishes. The optional 5-pin XLR connector for RMS monitoring is not offered on weather-protected models. Standard cabinets are built for indoor and touring use.

Can you pole-mount the ULTRA-X40 on top of a subwoofer?

Yes. The 750-LFC subwoofer includes an internal pole mount cup, so you can pole-mount an ULTRA-X40 directly on top of it for a compact ground-stacked system. This is a common setup for portable applications where floor space is limited.

What subwoofer pairs best with the Meyer ULTRA-X40?

The 750-LFC low-frequency control element is the natural match for the ULTRA-X40. It extends the system's response down to 36 Hz and is tuned to pair with the ULTRA-X40 in ground-stacked or pole-mounted setups without extra processing. For tighter spaces, the compact USW-112P is a lighter option.

How much does the ULTRA-X40 weigh, and how big is it?

The ULTRA-X40 weighs about 52 pounds (under 25 kg) and measures roughly 22.3 in high by 12.5 in wide by 14 in deep. It is more than 20 pounds lighter than the UPA-1P it replaced, so one person of average strength can lift it onto a stand.

Can the ULTRA-X40 be used as a floor monitor?

No. The ULTRA-X40 is not designed for use as a stage floor monitor. It is built for front-of-house, front-fill, and installed coverage. It mounts on a pole, yoke, U-bracket, or flown rigging instead.
