Ashly

Ashly ne4250.70 Network-Enabled 250W Four-Channel 70V Amplifier

$2,019.00

The ne4250.70 is built on an energy-efficient Class-D platform with a switching power supply for reliable performance. Its network capabilities allow for remote control and monitoring of amplifier functions via standard 10/100 Ethernet and Ashly's Protea NE Software.

View Product Features

• 4-channel amplifier: Delivers 250W per channel at 70V constant voltage.
• Network control: Standard 10/100 Ethernet for remote monitoring via Protea NE software.
• Class-D output: Energy-efficient and reliable performance.
• Bridgeable channels: Channels can be bridged for higher power output (500W at 140V).
• Selectable HPF: Software-controlled high-pass filters to protect speakers.
• Remote control capabilities: Supports remote standby, level control, and preset recall.
• Expandable: Optional modules for network audio inputs like Dante or CobraNet.
• LED indicators: Front-panel LEDs show power, standby, protect, network communications, and signal levels.
• Standardized connectors: Uses Euroblock inputs and outputs for secure wiring.

In stock

Scroll below to see our current inventory for this item.

Already own this item and want to sell it?

About the Ashly ne4250.70 Network-Enabled 250W Four-Channel 70V Amplifier

The Ashly ne4250.70 is a network-enabled four-channel power amplifier specifically engineered for large-scale commercial distributed audio systems. Each channel delivers efficient Class D amplification, rated at 250 watts, and is configured to directly drive 70V and 100V constant-voltage speaker lines. This integrated design eliminates the need for external output transformers, simplifying installation and providing a clean, centralized solution for background music, paging, and multi-zone audio in venues such as shopping malls, airports, hotels, and educational campuses. The amplifier is built for reliable, continuous operation, focusing on delivering consistent power over long speaker runs with minimal signal degradation.

A key feature of the ne4250.70 is its network connectivity, provided through a standard Ethernet port. This allows the amplifier to be integrated into a local area network for comprehensive remote control, configuration, and monitoring via Ashly's proprietary software or compatible third-party control systems. While this model emphasizes amplification and network control, it provides essential system management capabilities, enabling technicians to adjust output levels, monitor for faults, and manage system-wide parameters from a central computer. This remote accessibility simplifies maintenance and operational adjustments in large, dispersed installations.

Housed in a space-saving 1U rack-mountable chassis, the ne4250.70 is designed for high-density installations where rack space is at a premium. It includes protection against common faults such as thermal overload and short circuits to ensure system longevity. By combining constant-voltage output capability with networked control in a compact form factor, the Ashly ne4250.70 represents a practical and efficient building block for modern commercial sound systems, facilitating scalable and easily managed audio infrastructure.

Key Features

• 4-channel amplifier: Delivers 250W per channel at 70V constant voltage.
• Network control: Standard 10/100 Ethernet for remote monitoring via Protea NE software.
• Class-D output: Energy-efficient and reliable performance.
• Bridgeable channels: Channels can be bridged for higher power output (500W at 140V).
• Selectable HPF: Software-controlled high-pass filters to protect speakers.
• Remote control capabilities: Supports remote standby, level control, and preset recall.
• Expandable: Optional modules for network audio inputs like Dante or CobraNet.
• LED indicators: Front-panel LEDs show power, standby, protect, network communications, and signal levels.
• Standardized connectors: Uses Euroblock inputs and outputs for secure wiring.

Ashly ne4250.70 Network-Enabled 250W Four-Channel 70V Amplifier Specs

Amplifier Output
Channels
4
Amplifier Class
Class D
Output Voltage
70V, 100V
Network & Control
Control Interface
Ethernet
Remote Management
Yes
Monitoring
Fault & Status
Power Specifications
Power per Channel
250W
Physical Design
Rack Units
1 U
Connections
Speaker Output
Screw Terminal
Network Port
RJ45 Ethernet

Key Features

• 4-channel amplifier: Delivers 250W per channel at 70V constant voltage.
• Network control: Standard 10/100 Ethernet for remote monitoring via Protea NE software.
• Class-D output: Energy-efficient and reliable performance.
• Bridgeable channels: Channels can be bridged for higher power output (500W at 140V).
• Selectable HPF: Software-controlled high-pass filters to protect speakers.
• Remote control capabilities: Supports remote standby, level control, and preset recall.
• Expandable: Optional modules for network audio inputs like Dante or CobraNet.
• LED indicators: Front-panel LEDs show power, standby, protect, network communications, and signal levels.
• Standardized connectors: Uses Euroblock inputs and outputs for secure wiring.
