Magenta

Magenta MultiView UTx Universal Transmitter

$25.00 - $49.99

Magenta Research’s MultiView™ UTx Universal Transmitter is designed to facilitate the sourcing of professional-quality video, audio and control signal distribution over Cat5 for distances to 2,000 feet (610 meters) at resolutions of 1920x1200. Designed for quick and easy installation, the UTx is completely compatible with Magenta’s full product line of receivers, switches and distribution amplifiers.

View Product Features
  • Signals sent over Cat5: The UTx extends VGA video, stereo audio, and RS-232 serial control signals over a single Cat5 cable.
  • Wired connectivity: It has a wired connection, with an HD15 connector for the VGA input and ports for audio and serial connections.
  • Used with receivers: The transmitter sends signals to a corresponding MultiView receiver, such as the AK600 or 500 series, which are placed at the display end.
  • Variable configurations: The MultiView system offers versions for video and audio, or video and serial data. Some versions, like the SA/SAP series, could send all three over a single Cat5 cable.
  • Power requirement: The UTx transmitter requires a 5V DC power adapter, which is often not included in used equipment listings.
Out of Stock
0 in stock

Once stock replenishes, inventory will display below.

In-Stock Inventory

    No products currently in stock

Already own this item and want to sell it?

Click here to sell your item

About the Magenta MultiView UTx Universal Transmitter

The Magenta MultiView UTx Universal Transmitter is a professional AV signal transmission device designed to extend video, audio, and control signals over standard twisted pair cabling. It is part of Magenta’s MultiView product family and is commonly used in commercial AV, education, control room, and corporate environments where long-distance signal distribution is required with high reliability.

The UTx transmitter supports a wide range of video source formats, making it a flexible solution for mixed-signal environments. By converting source signals for transmission over Cat5/6 cabling, it enables long cable runs while maintaining signal integrity and reducing installation complexity compared to traditional coaxial or VGA cabling.

Designed for system integration, the unit supports bidirectional control and audio transmission when paired with compatible MultiView receivers. This allows centralized management of displays and source devices, improving operational efficiency in distributed AV systems.

With a compact form factor and rugged construction, the Magenta MultiView UTx is well suited for permanent installations as well as retrofit projects. Its versatility, reliability, and compatibility with Magenta receiver units make it a dependable choice for professional signal extension applications.

Key Features

  • Signals sent over Cat5: The UTx extends VGA video, stereo audio, and RS-232 serial control signals over a single Cat5 cable.
  • Wired connectivity: It has a wired connection, with an HD15 connector for the VGA input and ports for audio and serial connections.
  • Used with receivers: The transmitter sends signals to a corresponding MultiView receiver, such as the AK600 or 500 series, which are placed at the display end.
  • Variable configurations: The MultiView system offers versions for video and audio, or video and serial data. Some versions, like the SA/SAP series, could send all three over a single Cat5 cable.
  • Power requirement: The UTx transmitter requires a 5V DC power adapter, which is often not included in used equipment listings.

Magenta MultiView UTx Universal Transmitter Specs

Video
Supported Video Signals
VGA, RGBHV, component video
Maximum Resolution
Up to 1920 × 1200
Video Transmission Medium
Cat5e or Cat6 twisted pair
Audio
Audio Support
Stereo audio
Audio Transmission
Embedded over twisted pair
Control
Control Signals
RS-232
Bidirectional Control
Yes
Connectivity
Video Input Connector
HD15 (VGA)
Audio Input Connector
3.5 mm stereo
Twisted Pair Output
RJ45
Performance
Maximum Transmission Distance
Up to 1,000 ft (305 m)
Signal Integrity
Optimized for long-distance transmission
Electrical
Power Requirement
External power supply
Physical
Form Factor
Compact standalone module
Construction
Metal enclosure
Environmental
Operating Temperature
0 °C to 40 °C
Humidity
10% to 90% non-condensing

Key Features

  • Signals sent over Cat5: The UTx extends VGA video, stereo audio, and RS-232 serial control signals over a single Cat5 cable.
  • Wired connectivity: It has a wired connection, with an HD15 connector for the VGA input and ports for audio and serial connections.
  • Used with receivers: The transmitter sends signals to a corresponding MultiView receiver, such as the AK600 or 500 series, which are placed at the display end.
  • Variable configurations: The MultiView system offers versions for video and audio, or video and serial data. Some versions, like the SA/SAP series, could send all three over a single Cat5 cable.
  • Power requirement: The UTx transmitter requires a 5V DC power adapter, which is often not included in used equipment listings.
