Blackmagic Design ATEM 1 M/E Production Switcher

$199.00 - $399.00

Items Included

Item Notes

Condition: Out of stock
Once stock replenishes, inventory will display below.
Price
Sold out
Pre-Owned Guarantee 14 Day Return Window
Trade-In & SAVE Click Here To Get Started

Description

Get the workflow of a traditional 1 M/E SDI switcher combined with a very portable compact 2 RU size and a software control panel you can run on your laptop! Includes 4 SDI inputs, 4 HDMI inputs for consumer cameras or computers, analog input, and SDI, HDMI and analog outputs including down converted SDI output and USB 3.0. Read more

Features

  • Standards Conversion: Each input has full standards/format conversion.
  • Built-in Audio Mixer: 28-channel Fairlight audio mixer with EQ.
  • Multiple Keyers: Four upstream, one downstream keyers available.
  • Multiview Monitoring: Monitor up to 16 sources on one screen.
  • Digital Video Effects (DVE): Create picture-in-picture or DVE transitions.
  • Software/Hardware Control: Operate via free software or optional hardware panels.

Business Financing Options Avaiable

View Available Financing

Get the workflow of a traditional 1 M/E SDI switcher combined with a very portable compact 2 RU size and a software control panel you can run on your laptop! Includes 4 SDI inputs, 4 HDMI inputs for consumer cameras or computers, analog input, and SDI, HDMI and analog outputs including down converted SDI output and USB 3.0. Read more

Features

  • Standards Conversion: Each input has full standards/format conversion.
  • Built-in Audio Mixer: 28-channel Fairlight audio mixer with EQ.
  • Multiple Keyers: Four upstream, one downstream keyers available.
  • Multiview Monitoring: Monitor up to 16 sources on one screen.
  • Digital Video Effects (DVE): Create picture-in-picture or DVE transitions.
  • Software/Hardware Control: Operate via free software or optional hardware panels.

Recommended Accessories

    No products currently in stock

Frequently Purchased Together

    No products currently in stock

About the Blackmagic Design ATEM 1 M/E Production Switcher

The Blackmagic Design ATEM 1 M/E Production Switcher is a professional live video production console that integrates a comprehensive suite of broadcast-quality features into a compact and cost-effective hardware unit. Designed for live events, broadcast studios, web streaming, and corporate productions, this switcher provides a single Mix Effects (M/E) bank with multiple layers of keying, transitions, and downstream processing. It serves as the central hub for video switching, allowing operators to seamlessly cut, mix, and transition between multiple camera feeds, graphics, and media players in real-time, all while maintaining broadcast-standard video quality.

The switcher supports a wide array of input and output connections, including professional SDI and HDMI interfaces, accommodating cameras, media servers, graphics systems, and recording devices. Its feature set includes two independent keyers per M/E bank for adding titles, logos, or picture-in-picture effects, as well as a dedicated downstream keyer for final overlay adjustments. Built-in advanced chroma keying with support for 3D LUTs enables high-quality green screen effects, while a comprehensive media pool allows for instant playback of stills and clips. The unit also incorporates a multiview output that displays all sources, program, and preview on a single monitor, providing the director with complete situational awareness.

Control is highly flexible, offering integration with both the dedicated hardware control panel (sold separately) and software control via a computer running the ATEM Software Control application. This allows for scalable production setups, from a simple laptop-based operation to a full studio configuration. The switcher also includes streaming encoder functionality, enabling direct live broadcast to platforms like YouTube and Facebook. By packing professional live production capabilities into an accessible, all-in-one hardware solution, the ATEM 1 M/E empowers a broad range of users to produce polished, dynamic live video content with efficiency and creative control.

Key Features

  • Standards Conversion: Each input has full standards/format conversion.
  • Built-in Audio Mixer: 28-channel Fairlight audio mixer with EQ.
  • Multiple Keyers: Four upstream, one downstream keyers available.
  • Multiview Monitoring: Monitor up to 16 sources on one screen.
  • Digital Video Effects (DVE): Create picture-in-picture or DVE transitions.
  • Software/Hardware Control: Operate via free software or optional hardware panels.

Already own this item and want to sell it?

Click here to sell your item

Blackmagic Design ATEM 1 M/E Production Switcher Specs

Switcher Core
Mix Effects Banks
1 M/E
Programmable Buttons
4
Transition Types
Cut, Mix, Dip, Wipe, DVE
Input & Output
Video Inputs
10 (4x 3G-SDI, 4x HDMI, 2x optional card)
Video Outputs
5 (Program, Preview, Aux, 2x Multiview)
Reference Input
Blackburst or Tri-level sync
Keying & Effects
Keyers
2 upstream keyers per M/E, 1 downstream keyer
Chroma Key
Advanced with spill suppression & 3D LUT support
Media Pool
2 media players (for stills & clips)
Streaming & Control
Live Streaming
Built-in hardware streaming encoder
Control Interfaces
Ethernet (for software control), RS-422
Software Control
ATEM Software Control application
Additional Features
Audio Mixer
Integrated stereo audio mixer with EQ
Frame Synchronizers
All inputs have frame sync

Key Features

  • Standards Conversion: Each input has full standards/format conversion.
  • Built-in Audio Mixer: 28-channel Fairlight audio mixer with EQ.
  • Multiple Keyers: Four upstream, one downstream keyers available.
  • Multiview Monitoring: Monitor up to 16 sources on one screen.
  • Digital Video Effects (DVE): Create picture-in-picture or DVE transitions.
  • Software/Hardware Control: Operate via free software or optional hardware panels.

Already own this item and want to sell it?

Click here to sell your item

FAQs about Blackmagic Design ATEM 1 M/E Production Switcher

What is the primary function of the Blackmagic ATEM 1 M/E Production Switcher?

The ATEM 1 M/E is a professional 1-rack-unit (1U) broadcast live production switcher designed for multi-camera live switching, church broadcasts, studio productions, and outside broadcast trucks. It delivers 1 Mix/Effects bank with advanced transition engines, keying, and multi-view monitoring.

What video inputs and formats are available on the switcher?

It features 8 total video inputs, providing 4 SDI inputs, 4 HDMI inputs, and 1 analog component/composite input. It supports standard-definition and high-definition broadcast video formats up to 1080i60 and 720p60 across both SDI and HDMI connections.

What outputs does the ATEM 1 M/E provide for broadcast and monitoring?

It provides dedicated SDI and HDMI Program outputs, an SDI Preview output, three independent SDI Auxiliary (Aux) outputs, and a down-converted composite/SDI output. It also includes both SDI and HDMI Multi-View outputs to display all cameras, preview, and program feeds on a single monitor.

How is the switcher controlled?

It can be operated from any Mac or Windows laptop via Ethernet using the included ATEM Software Control panel application. For tactile physical operation, it can also be paired with physical broadcast hardware like the ATEM 1 M/E Advanced Panel or legacy Broadcast Panels.

What compositing, keying, and DVE features are included?

The switcher includes 4 upstream keyers supporting chroma, luma, linear, and pattern keying, alongside 2 downstream keyers (DSK) for station bugs and lower thirds. It also features a built-in 2D Digital Video Effects (DVE) processor for picture-in-picture boxes, squeezes, and animated transitions.

Does the switcher feature an internal media pool for graphics?

Yes, it includes a built-in media pool that stores up to 32 still graphics with fill and alpha channels. You can load graphics directly into the media pool over Ethernet using the included Adobe Photoshop plug-in or the ATEM Software Control application.

How does the internal audio mixer handle sound?

The unit features an integrated digital audio mixer that de-embeds audio from all 8 video inputs (SDI and HDMI) and accepts external analog stereo audio through balanced XLR and RCA inputs. It allows you to route audio, adjust levels, and configure Audio-Follow-Video (AFV) switching.
