TASCAM Sonicview 24XP 24-Channel Digital Mixing Console and Multitrack Recorder

$6,999.00

Audio professionals in search of a cutting edge digital mixer will be impressed with the TASCAM Sonicview 24XP, a next-generation multitrack recording and digital mixing console with multi-environment touchscreens, well suited for touring bands, concert halls, clubs, bars, special events, corporate meetings, and rental houses. Powered by a 96 kHz, 54-bit float-point FPGA mixing engine that utilizes 96 kHz / 32-bit AD/DA converters, the Sonicview 24XP provides 1st-class sonics with ultralow latency performance. Best of all, the hardware mixing surface and mix engine operate independently of each other for a highly stable and continuous audio workflow.

The Sonicview 24XP features 24+1 motorized faders and three 7" touchscreen displays, as well as 24 XLR inputs, each with TASCAM's HDIA preamps for high-definition recording and playback. Channels 17-24 also feature balanced 1/4" inputs, while inputs 15 and 16 include 1/4" inserts. For outputs, the mixer includes 16 XLR outputs, plus XLR monitor outputs, as well as 1/4" and 3.5mm headphone outputs. Each input channel includes 11 processing functions including trim, HPF, 4-band EQ, dynamics, and more. There are four stereo multi-effects processors available to add that special sauce to your mix. The mixer is equipped with Dante I/O, Ethernet, and a GPIO connection for events and relay applications. The Sonicview ships with the IF-MTR32 multitrack recording card preinstalled.

View Product Features

  • FPGA Mix Engine + 32-Bit / 96 kHz AD/DA
  • 3 x 7" Touchscreens + Motorized Faders
  • 24 HDIA Microphone Preamps
  • 24 XLR Mic/Line Input Channels
  • 8 x 1/4" Line Inputs + 2 x 1/4" Inserts
  • 16 XLR Bus / Outputs
  • 11 Processing Functions per Input
  • Including EQ, Dynamics, Filter and More
  • 32-In x 32-Out USB and SD-Card Recording
  • Four Stereo Effects Engines
In stock

Scroll below to see our current inventory for this item.

Already own this item and want to sell it?

About the TASCAM Sonicview 24XP 24-Channel Digital Mixing Console and Multitrack Recorder

Audio professionals in search of a cutting edge digital mixer will be impressed with the TASCAM Sonicview 24XP, a next-generation multitrack recording and digital mixing console with multi-environment touchscreens, well suited for touring bands, concert halls, clubs, bars, special events, corporate meetings, and rental houses. Powered by a 96 kHz, 54-bit float-point FPGA mixing engine that utilizes 96 kHz / 32-bit AD/DA converters, the Sonicview 24XP provides 1st-class sonics with ultralow latency performance. Best of all, the hardware mixing surface and mix engine operate independently of each other for a highly stable and continuous audio workflow.

The Sonicview 24XP features 24+1 motorized faders and three 7" touchscreen displays, as well as 24 XLR inputs, each with TASCAM's HDIA preamps for high-definition recording and playback. Channels 17-24 also feature balanced 1/4" inputs, while inputs 15 and 16 include 1/4" inserts. For outputs, the mixer includes 16 XLR outputs, plus XLR monitor outputs, as well as 1/4" and 3.5mm headphone outputs. Each input channel includes 11 processing functions including trim, HPF, 4-band EQ, dynamics, and more. There are four stereo multi-effects processors available to add that special sauce to your mix. The mixer is equipped with Dante I/O, Ethernet, and a GPIO connection for events and relay applications. The Sonicview ships with the IF-MTR32 multitrack recording card preinstalled.

Key Features

  • FPGA Mix Engine + 32-Bit / 96 kHz AD/DA
  • 3 x 7" Touchscreens + Motorized Faders
  • 24 HDIA Microphone Preamps
  • 24 XLR Mic/Line Input Channels
  • 8 x 1/4" Line Inputs + 2 x 1/4" Inserts
  • 16 XLR Bus / Outputs
  • 11 Processing Functions per Input
  • Including EQ, Dynamics, Filter and More
  • 32-In x 32-Out USB and SD-Card Recording
  • Four Stereo Effects Engines

TASCAM Sonicview 24XP 24-Channel Digital Mixing Console and Multitrack Recorder Specs

Mixer
Max I/O Capacity
52x Input / 32x Output (with Optional Hardware)
Number of Analog Input Channels
24 (24 Mono / 4 Stereo)
Number of Mic Preamps
24
Number of Analog Output Channels
16
Mix Routing
1x Main LRC 4x Mono Subgroup 4x Mono Aux Send
Groups
8x DCA Group
Presets
No
Display
Main Display: 7" LCD Touchscreen
Faders & Level Adjustment
25x 3.9" / 100 mm Motorized Fader(Touch Sensitive)
Meters
Main Meter: 2x 24-Segment LED
Signal Processing
Input Pad
-20 dB
Input Polarity
Normal/Reverse
Dynamic Processing
Input Channels: Compressor, Gate Buses, Master: Compressor
EQ
Input Channels: 4-Band Parametric Output Buses: 31-Band Graphic 4-Band Parametric
Graphic EQ
Yes
Filters
Input Channels: High-Pass
Solo/Mute
Solo, Mute per Input Channel, Bus, FX Bus, Master
Built-In Effects
4x Stereo Effect (Type Unspecified)
Audio Delay
Yes
Automatic Mic Mixing
No
Digital Audio
Sample Rates
Up to 96 kHz
Bit Depth
32-Bit
Performance
Frequency Response
Mic/Line InputLine : 20 Hz to 40 kHz +0/-1 dB (at 96 kHz) 20 Hz to 20 kHz 0/-0.5 dB (at 48 kHz)
Max Input Level
Mic/Line Input: +32 dBu at Max Gain Mic/Line Input: -62 dBV at Min Gain
Analog Dynamic Range
108 dB at Min Gain
Headphone Output Power
1/4": 100 mW per Channel into 32 Ohms (Max) I/O Impedance
THD
< 0.002% at Min Gain (+4 dBu)
Signal Generator
No
Connectivity
Analog Inputs
24x XLR 3-Pin Balanced Mic/Line Input 8x 1/4" TRS Balanced/Unbalanced Line Input 2x 1/4" Unbalanced Insert Insert 1x XLR 3-Pin Balanced Talkback Input 1x DB-25 25-Pin Alt Input 2x Stereo RCA TS Stereo 2-Track Input
Analog Outputs
16x XLR 3-Pin Balanced Main/Bus Output 2x XLR 3-Pin Balanced Monitor Output 1x 1/4" TRS Headphone Output 1x 1/8" / 3.5 mm TRS Headphone Output
Phantom Power
+48 V
Digital I/O
1x RJ45 Ethernet Input/Output (Network) 2x RJ45 Dante Input/Output (I/O, Network)
MIDI I/O
No
USB I/O
1x USB-B (Host Connection) 1x USB-A (2-Track Record, Audio Playback, External Memory)
Expansion Ports
1x I/O Card
Wireless
No
External Display I/O
No
Recording
Max Multitrack Recording
32 Tracks
Media Support
SD, SDHC, USB Drive
Max Media Storage Capacity
SD: 32 GB SDHC: 128 GB USB: 128 GB
File Format Support
Playback: AAC, MP3, WAV Record: WAV
Compatibility
OS Compatibility
Computer: Windows 10 or Later / macOS 10.15 to 12 Mobile: iPadOS Only
Mobile Device Compatibility
iPad
Power
Input Power
100 to 240 VAC, 50 / 60 Hz
Physical
Rack Mountable
No
Dimensions
27.2 x 9 x 21.4" / 690.8 x 228.1 x 544.4 mm
Weight
39.7 lb / 18 kg

Key Features

  • FPGA Mix Engine + 32-Bit / 96 kHz AD/DA
  • 3 x 7" Touchscreens + Motorized Faders
  • 24 HDIA Microphone Preamps
  • 24 XLR Mic/Line Input Channels
  • 8 x 1/4" Line Inputs + 2 x 1/4" Inserts
  • 16 XLR Bus / Outputs
  • 11 Processing Functions per Input
  • Including EQ, Dynamics, Filter and More
  • 32-In x 32-Out USB and SD-Card Recording
  • Four Stereo Effects Engines
