Miranda EM0902 NVISION NV8500 3GIG SDI 9 COAX

The Miranda EM0902 is a professional coaxial cable assembly designed for high-definition and 3G-SDI video signal transmission in broadcast and production environments. This 9-coaxial cable, often used within the NVISION (and later Grass Valley) NV8500 series routing infrastructure, bundles nine individual 75-ohm coaxial cables into a single, manageable outer jacket. Each coax within the bundle is terminated with a BNC connector, providing a robust and organized solution for routing multiple SDI signals between frames, routers, and other core video processing equipment in a broadcast facility, mobile production truck, or data center. Its primary function is to maintain signal integrity over moderate distances while significantly reducing cable clutter compared to using nine separate loose cables.

Constructed with broadcast-grade materials, the cable is engineered for low signal loss and excellent shielding to minimize electromagnetic interference (EMI), which is critical for preserving the quality of high-bandwidth 3G-SDI signals. The bundled design, often with numbered or color-coded connectors, simplifies installation, troubleshooting, and maintenance by keeping related signal paths neatly organized. These cable assemblies are typically used for internal frame-to-frame connections within large routing systems, such as connecting an NV8500 router's input or output matrix to other frames or peripheral equipment like distribution amplifiers or converters.

As a dedicated component for professional broadcast infrastructure, the Miranda EM0902 9-coax cable ensures reliable, high-density signal interconnection. It supports the complex signal routing required in modern television facilities, where hundreds of video sources and destinations must be managed efficiently and reliably.
