Sennheiser

Sennheiser XSW IEM EK (A) Stereo Bodypack Wireless Receiver with IE 4 Earphones (A: 476 to 500 MHz)

$379.00

With the XS Wireless IEM, you can easily link additional receivers to one transmitter – connecting more band members to a new level of detail. The lightweight bodypack remains unnoticed once clipped on your clothing or belt. You can plug in the included IE 4 in-ear monitors or upgrade to the IE PRO series with the 3.5 mm output. The status LED shows battery and link status at a glance – while the high contrast front panel allows for individual fine-tuning, from balance to focus modes to EQ to Limiter, so you can design your individual mix. A professional IEM receiver is unnoticeable most of the time, but becomes a powerful tool with just a few clicks. That is the DNA of the lightweight XS Wireless IEM bodypack. You can easily expand any XS Wireless IEM setup by connecting additional receivers to your transmitter. Its small status LED is all you might see during rehearsals or gigs. It signals both battery and wireless link status. The LC display only lights up when you access the well-secured settings panel. With just a few clicks, you can balance your in-ear mix, switch between focus modes, use an EQ for elevated high frequencies, enable the limiter, choose a new option from the preset channels, or set your frequency manually. The standard 3.5 mm output is open for the included pair of IE 4 in-ear monitors – or you can upgrade your sound with a model of the IE PRO in-ear monitor line. Advanced features like the limiter help you to protect your ears by clamping down on sudden loud signals. With the EQ option, you can get more air and extra brightness by boosting your sound at 13 kHz. The bodypack operates with two AA primary cells or rechargeable batteries. Depending on the volume level, you can expect about six hours of operating time.

View Product Features

  • Works with XSW IEM SR Stereo Transmitter
  • Lightweight and Compact Body
  • Volume, Stereo Panning, Focus Mode
  • Integrated High-Boost EQ and Limiter
  • 6 Hours on Two AA Batteries
In stock

Scroll below to see our current inventory for this item.

Already own this item and want to sell it?

About the Sennheiser XSW IEM EK (A) Stereo Bodypack Wireless Receiver with IE 4 Earphones (A: 476 to 500 MHz)

The Sennheiser XSW IEM EK (A) is a professional-grade wireless in-ear monitoring system packaged as a complete solution for performing musicians, vocalists, and public speakers. This kit includes a compact stereo bodypack receiver and a matched pair of Sennheiser IE 4 dynamic earphones, designed to operate within the 476 to 500 MHz frequency range (A Band). The system provides a critical, personal audio feed directly to the user, eliminating the need for bulky stage monitors and reducing the risk of audio feedback while allowing for greater stage mobility and a cleaner stage setup. The bodypack receiver is constructed with a robust, lightweight housing that features a clip for secure attachment to clothing or a belt, along with a simple user interface consisting of a volume wheel, power switch, and a multi-color LED that provides clear visual status updates for power, audio signal, and RF stability.

Audio fidelity is a central focus, with the receiver employing a compander-free signal path to ensure natural sound reproduction without the processing artifacts that can affect tone and transients. The integrated true diversity reception system, utilizing two internal antennas, actively combats signal dropouts and interference by continuously selecting the strongest RF signal, which is essential for maintaining a reliable wireless link in environments with multiple wireless systems. The included IE 4 earphones are engineered for clarity and comfort, featuring an ergonomic over-the-ear design that provides a secure fit and effective passive noise isolation. This isolation allows performers to hear their mix clearly at lower, safer volume levels, which is crucial for long-term hearing preservation during rehearsals and extended performances.

The system is designed for straightforward setup and operation, making it accessible for both new users and seasoned professionals. It includes a dedicated belt clip that securely holds the bodypack and manages the earphone cable to prevent strain on the connectors. The receiver is powered by a single AA battery, offering a full day's use on a single charge, and features a standard 3.5mm input jack for connecting to a mixer's monitor output via an appropriate cable. As an integrated package, the Sennheiser XSW IEM EK (A) delivers a reliable, high-quality wireless monitoring experience, providing performers with the precise audio control and freedom of movement necessary to deliver confident, engaging performances.

Key Features

  • Works with XSW IEM SR Stereo Transmitter
  • Lightweight and Compact Body
  • Volume, Stereo Panning, Focus Mode
  • Integrated High-Boost EQ and Limiter
  • 6 Hours on Two AA Batteries

Sennheiser XSW IEM EK (A) Stereo Bodypack Wireless Receiver with IE 4 Earphones (A: 476 to 500 MHz) Specs

Wireless Specifications
Frequency Band
A Band (476-500 MHz)
Tuning Steps
125 kHz
RF Stability
±15 PPM
Modulation Bandwidth
66 kHz
Max RF Input Level
+10 dBm
Receiver Performance
Audio Bandwidth
35 Hz - 18 kHz
Dynamic Range
>100 dB
Total Harmonic Distortion
<1.0% (1 kHz)
Pilot Tone Muting
Yes
Bodypack Unit
Input Connector
3.5 mm stereo jack
Output Connector
3.5 mm stereo jack
Battery Type
1 x AA alkaline/NiMH
Operating Time
Approx. 10 hours (alkaline)
Dimensions (H x W x D)
67 x 56 x 24 mm
Weight (excl. battery)
85 g
Earphones Specifications
Model
Sennheiser IE 4
Transducer Principle
Dynamic
Nominal Impedance
18 Ω
Sound Pressure Level (SPL)
110 dB (1 kHz / 1 Vrms)
Cable Length
1.2 m straight
Coupling to Ear
Over-ear, close-fit
System Operation
Operating Range
>100 m (free field)
Diversity System
True diversity, 2 antennas
Channel Compatibility
12 user-selectable channels

Key Features

  • Works with XSW IEM SR Stereo Transmitter
  • Lightweight and Compact Body
  • Volume, Stereo Panning, Focus Mode
  • Integrated High-Boost EQ and Limiter
  • 6 Hours on Two AA Batteries
