Doug Fleenor Design

Doug Fleenor Design 96-Ch DMX Relay Pack

$360.00

The Doug Fleenor Design 96-Ch DMX Relay Pack (Model DMX96OC) is a specialized interface unit designed to convert DMX512 lighting control signals into 96 individual low-voltage, open-collector NPN outputs. It is ideal for driving external solenoids, relays, fountains, and other on/off loads in special effects or architectural applications where a true "off" (no current leakage) condition is required.

View Product Features

Decodes 96 consecutive DMX512 channels for on/off control.
DMX input is optically isolated for protection up to 120 volts.
Each output sinks up to 100mA continuous current (500mA peak).
Starting DMX address set via easy-to-read three-digit thumbwheel switch.
Features power, signal, and output 1 mimic indicator LEDs on the front panel.
Output connections provided via four female DB-25 connectors with gold-plated contacts.

Out of Stock

0 in stock

Once stock replenishes, inventory will display below.

In-Stock Inventory

Already own this item and want to sell it?

Click here to sell your item

About the Doug Fleenor Design 96-Ch DMX Relay Pack

Key Features

Decodes 96 consecutive DMX512 channels for on/off control.
DMX input is optically isolated for protection up to 120 volts.
Each output sinks up to 100mA continuous current (500mA peak).
Starting DMX address set via easy-to-read three-digit thumbwheel switch.
Features power, signal, and output 1 mimic indicator LEDs on the front panel.
Output connections provided via four female DB-25 connectors with gold-plated contacts.

Doug Fleenor Design 96-Ch DMX Relay Pack Specs

Key Features

Decodes 96 consecutive DMX512 channels for on/off control.
DMX input is optically isolated for protection up to 120 volts.
Each output sinks up to 100mA continuous current (500mA peak).
Starting DMX address set via easy-to-read three-digit thumbwheel switch.
Features power, signal, and output 1 mimic indicator LEDs on the front panel.
Output connections provided via four female DB-25 connectors with gold-plated contacts.
