Doug Fleenor Design | SKU: C1612-134

Doug Fleenor Design 96-Channel DMX Relay Pack

Name: Doug Fleenor Design 96-Channel DMX Relay Pack
Brand: AVGear.com
SKU: C1612-134
Price: 360.00 USD
Availability: OutOfStock

$360.00 ~~$600.00~~

Shipping calculated at checkout.

Cosmetic Rating

Good

Items in "Good Condition" are well-maintained and show typical signs of regular use, such as light scratches, minor dents, or slight discoloration from tag removal. All essential parts are intact, and the equipment remains in great working order. Ideal for budget-conscious buyers seeking reliable, high-quality gear.

For used equipment, the images displayed reflect the exact item and contents included, unless otherwise specified in the product description.

Already own this item and want to sell it?

Click here to sell your item

Description

The DMX96OC is designed to drive solenoids and relays for fountains or special effects, and is ideal for many other on/off loads. The product decodes 96 consecutive DMX512 channels to drive open-collector NPN outputs. Each of the outputs is capable of sinking up to 100mA (or more based on duty cycle). The DMX512 input is optically isolated from the outputs and is protected against miswiring up to 120 volts. DFD also makes a single channel DIN rail mounted version model DININTR.

Features

Input baud rate: DMX512: 250 Kb/sOutput circuit: 8-bit 50V 500mA NPN Darlington driverOutput signal: VCE(SAT) 1.1V maximum at 100mAMax. output current: 100mA continuous, 500mApeakMax. output voltage: 48VDC

Testing Notes

Used.

In The Box

Doug Fleenor Design 96-Channel DMX Relay Pack
