SKU: C1365-40-1

Crestron HD-RX-101-C-E Surface Mountable DM Lite Receiver (New - Sealed Box)

$20.40 ~~$60.00~~

Items Included

Crestron HD-RX-101-C-E Surface Mountable DM Lite Receiver (New - Sealed Box)

Item Notes

New.

Condition: Fully Working 5 availableⓘ

5 availableⓘ View All

Note: Each item is unique. please check individual listings for details.

Pre-Owned Guarantee 14 Day Return Window

Trade-In & SAVE Click Here To Get Started

Description

The HD-RX-101-C-E is a surface-mountable DM Lite receiver designed to pair with a DM Lite transmitter to form a point-to-point signal extender for HDMI® signals. The DM Lite family of products offers a very simple and versatile solution for extending HD, UHD, 2K, and 4K video signals, with stereo or surround sound audio, over a single CAT5e (or better) cable. A cable length of up to 230 ft (70 m) is supported for HD 1080p, WUXGA, and 2K signals, or up to 130 ft (40 m) for UHD and 4K. Read more

Features

Pairs with a DM Lite transmitter to provide a simple point-to-point signal extender
Enables extension of HDMI® video and audio signals
Links to the transmitter via a single CAT5e (or better) twisted pair cable
Supports 4K and UHD at up to 130 ft (40 m)
Supports HD 1080p, WUXGA, and 2K at up to 230 ft (70 m)

Business Financing Options Avaiable

View Available Financing

Features

Pairs with a DM Lite transmitter to provide a simple point-to-point signal extender
Enables extension of HDMI® video and audio signals
Links to the transmitter via a single CAT5e (or better) twisted pair cable
Supports 4K and UHD at up to 130 ft (40 m)
Supports HD 1080p, WUXGA, and 2K at up to 230 ft (70 m)

No products currently in stock

About the Crestron HD-RX-101-C-E Surface Mountable DM Lite Receiver (New - Sealed Box)

The DMC-4K-HDO is an output card designed for use with any card-based Crestron® DigitalMedia™ Switcher. It provides two independent HDMI® outputs with complementary balanced analog stereo audio outputs. The HDMI outputs are each capable of handling Full HD 1080p, Ultra HD, 2K, and 4K video signals. Built-in 4K/60 scaling enables devices connected to either HDMI output to handle any video resolution from NTSC 480i to DCI 4K. DVI signals are also supported using HDMI-to-DVI adapters or interface cables.[1]

4K Ultra HD
The DMC-4K-HDO is capable of handling video resolutions up to 4K and Ultra HD. Support for 4K video also ensures support for the latest generation of computers and monitors with native resolutions beyond 1080p and WUXGA.

4K/60 Scalers
An independent, high-performance 4K scaler is provided at each output to ensure that input sources of any resolution or frame rate can be routed and displayed reliably on virtually any display device without compromising the original input signal. As part of a DM® switcher with many outputs, this allows any video or computer source to be viewed simultaneously on multiple disparate displays, scaling the signal up or down to match the native resolution of each display.

No matter what source is selected, or where it’s routed, the DMC-4K-HDO helps to ensure an optimal image on every screen. It can take any input resolution from standard definition NTSC 480i to ultra high-definition DCI 4K, and scale it beautifully to any output resolution up to DCI 4K (4096 x 2160 @ 60 Hz). Interlaced sources are converted to progressive scan using motion-adaptive deinterlacing. Intelligent frame rate conversion enables support for 24p and PAL format sources. 3D signals are converted to 2D.[2] Fully automatic operation eliminates any complicated setup by utilizing the displays’ EDID to configure each scaler.[3]

Video Wall Processing
The DMC-4K-HDO has another trick up its sleeve, providing zoom capability and bezel compensation on each output to display just a portion of the source image. Using this feature, up to 32 output cards may be combined to provide processing for a video wall composed of up to 64 individual displays. Video wall configurations up to eight wide by up to eight high are supported.

Audio De-embedding
Each HDMI output on the DMC-4K-HDO is accompanied by a balanced analog audio output, allowing stereo audio signals to be extracted from the digital stream and fed to a sound system. The output volume is adjustable via a control system using a keypad, touch screen, handheld remote, or mobile device.[4]

CEC Embedded Device Control
DigitalMedia offers an alternative to conventional RS-232 and IR display control by harnessing the CEC (Consumer Electronics Control) signal embedded in HDMI. Through its connection to a control system (via the DM switcher), the DMC-4K-HDO provides a gateway for controlling display devices right through their HDMI connections, potentially eliminating the need for any dedicated control wires or IR emitters.

To configure a DM switcher complete with input and output cards, cables, and other peripherals, please use the online DigitalMedia Switcher Configuration Tool.

Key Features

Pairs with a DM Lite transmitter to provide a simple point-to-point signal extender
Enables extension of HDMI® video and audio signals
Links to the transmitter via a single CAT5e (or better) twisted pair cable
Supports 4K and UHD at up to 130 ft (40 m)
Supports HD 1080p, WUXGA, and 2K at up to 230 ft (70 m)

Already own this item and want to sell it?

Click here to sell your item

Crestron HD-RX-101-C-E Surface Mountable DM Lite Receiver (New - Sealed Box) Specs

Scalers

(2) 4K video scalers with motion-adaptive deinterlacing, intelligent frame rate conversion, Deep Color support, 3D to 2D conversion, content-adaptive noise reduction, widescreen format selection (zoom, stretch, maintain aspect-ratio, 1:1), video wall processing up to 8×8

Output Signal Types

HDMI with Deep Color & 4K (DVI compatible)

Maximum Resolution (Progressive)

4096×2160 DCI 4K / 3840×2160 4K UHD @ 24 Hz 4:4:4 30-bit, @30 Hz 4:4:4 24-bit, @30 Hz 4:2:2 36-bit, @60 Hz 4:2:0 24-bit

Maximum Resolution (Progressive)

2560×1600 WQXGA @ 60 Hz 4:4:4 36-bit

Maximum Resolution (Progressive)

1920×1080 1080p @ 60 Hz 4:4:4 36-bit

Maximum Resolution (Interlaced, input only)

1920×1080 1080i @ 30 Hz 4:4:4 36-bit

Supported Resolutions

Common and custom resolutions up to 300 MHz pixel clock

Audio Output Signal Types

HDMI, Analog Stereo

Digital Audio Formats

Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS, DTS-ES, DTS 96/24, DTS-HD High Resolution, DTS-HD Master Audio, LPCM up to 8 channels

Analog Audio Formats

Stereo 2-channel

Digital-to-Analog Conversion

24-bit 48 kHz

Analog Performance

Frequency Response 20 Hz–20 kHz ±0.5 dB, S/N >95 dB A-weighted, THD+N <0.005% @ 1 kHz, Stereo Separation >90 dB

Analog Volume Adjustment

-80 to 0 dB

HDMI Communications

HDCP 2.2, EDID, CEC

HDMI Management

Supports HDCP, EDID, and CEC control integration

HDMI Connectors

(2) HDMI Type-A 19-pin female, digital video/audio outputs, DVI compatible

Audio Output Connectors

(2) 5-pin 3.5 mm detachable terminal blocks, balanced/unbalanced stereo line-level

Output Impedance

200 ohms balanced, 100 ohms unbalanced

Maximum Output Level

4 Vrms balanced, 2 Vrms unbalanced

Construction

Plug-in card, occupies 1 DM switcher output card slot, metal faceplate black finish

Weight

6.2 oz (176 g)

Key Features

Pairs with a DM Lite transmitter to provide a simple point-to-point signal extender
Enables extension of HDMI® video and audio signals
Links to the transmitter via a single CAT5e (or better) twisted pair cable
Supports 4K and UHD at up to 130 ft (40 m)
Supports HD 1080p, WUXGA, and 2K at up to 230 ft (70 m)
