Crestron TPCS-4SM-W-S Touch Screen Control System

The Crestron TPCS-4SM-W-S is a highly integrated, space-saving AV control solution that combines a vibrant 4.3-inch color touch screen with a built-in Crestron 3-Series control processor in a single, wall-mounted chassis. Finished in a smooth white (White Smooth, hence "W-S"), this device is engineered to provide comprehensive room control without the need for a separate, rack-mounted equipment processor. Designed primarily for conference rooms, huddle spaces, and classrooms, it allows users to manage AV presentations, lighting, room scheduling, and HVAC through an intuitive, fully customizable graphical interface powered by Crestron Smart Graphics.

By integrating the 3-Series control engine directly into the touch panel, the TPCS-4SM drastically simplifies installation and minimizes wiring. It operates entirely over a single CAT-type network cable using Power over Ethernet (PoE), handling both communication and power delivery. Furthermore, the unit features a built-in proximity sensor to automatically wake the screen as a user approaches, alongside 10 optionally engravable hard-key pushbuttons with dual-color LED backlighting for quick, tactile access to common functions like volume or lights. If additional physical control interfaces (like IR, RS-232, or relays) are required to control local room displays or shades, the touch screen can easily be expanded using its integrated Cresnet master port combined with a compatible Crestron C2N-IO control module.
