Evertz 500A-3G 3G/HD/SD-SDI Reclocking Distribution Amplifier

$0.00

The Evertz 500A-3G is a 3G/HD/SD-SDI reclocking distribution amplifier designed for distributing serial digital video signals. It supports SMPTE 424M (3Gb/s), SMPTE 292M (1.5Gb/s), and SMPTE 259M (270Mb/s) standards. The module is housed within the 500FR frame, which can accommodate up to 16 modules.

View Product Features

Reclocking : The 500A-3G re-times and regenerates the signal, ensuring reliable signal distribution over longer distances and minimizing signal degradation.
Multiple Rates : It supports a wide range of data rates, including 3Gb/s, 1.5Gb/s, and 270Mb/s, making it versatile for various SDI applications.
Non-Reclocked Mode : It also supports other SMPTE standards like ST 344-1, ST 259-1, ST 310-1, and DVB-ASI in a non-reclocked mode at rates of 540MB/s, 360MB/s, 143Mbs/, and 19.4MB/s, respectively.
Hot-Swappable : The module can be hot-swapped from the front of the 500FR frame without requiring BNC disconnection.
Output Isolation : Each output driver is isolated to prevent cross-channel loading and signal interference.
Frame Compatibility : It is designed to be installed in the 3RU 500FR frame, which can hold up to 16 modules.

Out of Stock

0 in stock

Once stock replenishes, inventory will display below.

In-Stock Inventory

No products currently in stock

Already own this item and want to sell it?

Click here to sell your item

About the Evertz 500A-3G 3G/HD/SD-SDI Reclocking Distribution Amplifier

Key Features

Reclocking : The 500A-3G re-times and regenerates the signal, ensuring reliable signal distribution over longer distances and minimizing signal degradation.
Multiple Rates : It supports a wide range of data rates, including 3Gb/s, 1.5Gb/s, and 270Mb/s, making it versatile for various SDI applications.
Non-Reclocked Mode : It also supports other SMPTE standards like ST 344-1, ST 259-1, ST 310-1, and DVB-ASI in a non-reclocked mode at rates of 540MB/s, 360MB/s, 143Mbs/, and 19.4MB/s, respectively.
Hot-Swappable : The module can be hot-swapped from the front of the 500FR frame without requiring BNC disconnection.
Output Isolation : Each output driver is isolated to prevent cross-channel loading and signal interference.
Frame Compatibility : It is designed to be installed in the 3RU 500FR frame, which can hold up to 16 modules.

Evertz 500A-3G 3G/HD/SD-SDI Reclocking Distribution Amplifier Specs

Key Features

Reclocking : The 500A-3G re-times and regenerates the signal, ensuring reliable signal distribution over longer distances and minimizing signal degradation.
Multiple Rates : It supports a wide range of data rates, including 3Gb/s, 1.5Gb/s, and 270Mb/s, making it versatile for various SDI applications.
Non-Reclocked Mode : It also supports other SMPTE standards like ST 344-1, ST 259-1, ST 310-1, and DVB-ASI in a non-reclocked mode at rates of 540MB/s, 360MB/s, 143Mbs/, and 19.4MB/s, respectively.
Hot-Swappable : The module can be hot-swapped from the front of the 500FR frame without requiring BNC disconnection.
Output Isolation : Each output driver is isolated to prevent cross-channel loading and signal interference.
Frame Compatibility : It is designed to be installed in the 3RU 500FR frame, which can hold up to 16 modules.
