The Evertz 7736CDM-A4 is a professional analog-to-digital video converter module designed for the Evertz 7700 series modular platform. Its primary function is to digitize up to four channels of standard definition analog composite video (such as NTSC or PAL) into a digital video format, most likely standard definition serial digital interface (SD-SDI). This conversion process is essential in broadcast and production facilities that must integrate legacy analog sources—such as older VTRs, cameras, or test signal generators—into a modern, all-digital routing and processing infrastructure. By converting the analog signals to the SMPTE 259M SD-SDI standard, the module ensures these sources can be seamlessly switched, distributed, and recorded alongside contemporary digital equipment without quality degradation.

Engineered for reliable performance in a modular environment, the 7736CDM-A4 integrates into a 7700 series chassis, leveraging its robust power supply, cooling, and management systems. The module accepts four BNC inputs for analog composite video and performs high-quality digitization using a broadcast-grade analog-to-digital converter (ADC). It includes necessary signal conditioning such as automatic gain control, clamping, and filtering to produce a clean, stable digital output that meets broadcast specifications. Status and control are typically managed remotely via the Evertz system software, allowing engineers to monitor the health and configuration of the module from a central location.

As a bridge between analog legacy equipment and digital workflows, this converter module is a critical tool for facility migration and hybrid operations. It is commonly used in master control rooms, post-production suites, and archival systems where preserving access to analog content is necessary. By providing high-quality, multi-channel analog digitization within a scalable modular frame, it helps extend the life of valuable analog assets and simplifies the technical plant by consolidating conversion tasks into a managed, rack-efficient unit.
