SKU: 1890-54

Extron DA6 HD 4K PLUS HDMI Distribution Amplifier

$75.00

Items Included

Item Notes

Condition: Fully Working 5 availableⓘ

5 availableⓘ View All

Note: Each item is unique. please check individual listings for details.

Pre-Owned Guarantee 14 Day Return Window

Trade-In & SAVE Click Here To Get Started

Description

The Extron DA6 HD 4K PLUS is a professional 1-input, 6-output HDMI distribution amplifier designed to distribute a single HDMI source to six displays simultaneously while maintaining exceptional signal quality. Supporting HDMI 2.0b and data rates up to 18 Gbps, it handles resolutions up to 4096 x 2160 at 60 Hz (4:4:4), along with HDR, Deep Color, 3D, CEC, and HD lossless audio formats. Extron's EDID Minder® technology automatically manages EDID communication between connected devices, while Key Minder® continuously verifies HDCP authentication for reliable operation. Automatic input cable equalization, RS-232 and USB control, and convection cooling make the DA6 HD 4K PLUS an ideal solution for conference rooms, classrooms, digital signage, and professional AV installations Read more

Features

One HDMI input with six HDMI outputs.
Supports 4K/60 4:4:4 at 18 Gbps.
HDMI 2.0b and HDCP 2.3 compliant.
EDID Minder® automatic EDID management.
Key Minder® HDCP authentication.
USB and RS-232 control interfaces.
HDR, Deep Color, and HD audio support.

Business Financing Options Avaiable

View Available Financing

Features

One HDMI input with six HDMI outputs.
Supports 4K/60 4:4:4 at 18 Gbps.
HDMI 2.0b and HDCP 2.3 compliant.
EDID Minder® automatic EDID management.
Key Minder® HDCP authentication.
USB and RS-232 control interfaces.
HDR, Deep Color, and HD audio support.

No products currently in stock

About the Extron DA6 HD 4K PLUS HDMI Distribution Amplifier

The Extron DA6 HD 4K PLUS is a high-performance, 1-input to 6-output HDMI distribution amplifier engineered to split a single HDMI video source to six separate displays simultaneously. As part of Extron's "PLUS" series, it receives a significant bandwidth upgrade over standard 4K models, supporting HDMI 2.0b specifications with data rates up to 18 Gbps. This allows it to effortlessly handle uncompressed 4K and UHD video at a full 60 Hz with 4:4:4 chroma subsampling. It is fully compatible with High Dynamic Range (HDR10, HDR10+, and Dolby Vision) formats and lossless audio codecs like Dolby Atmos and DTS:X, making it an ideal choice for high-end digital signage, broadcast monitoring, and premium commercial AV integrations.

To ensure rock-solid reliability in complex routing environments, the DA6 HD 4K PLUS is equipped with a suite of Extron's proprietary integration technologies. It features EDID Minder to automatically manage EDID communication between the displays and the source, ensuring proper resolution output, alongside HDCP 2.3 compliance for seamless playback of encrypted content. Additionally, the unit features automatic color bit depth management, automatic input cable equalization to compensate for signal loss over long cable runs, and independent output muting via RS-232, allowing operators to preview content locally while muting the main displays. It is housed in a rugged, 1U half-rack width metal enclosure with an internal universal power supply, designed for neat installation in standard AV racks.

Key Features

One HDMI input with six HDMI outputs.
Supports 4K/60 4:4:4 at 18 Gbps.
HDMI 2.0b and HDCP 2.3 compliant.
EDID Minder® automatic EDID management.
Key Minder® HDCP authentication.
USB and RS-232 control interfaces.
HDR, Deep Color, and HD audio support.
