MA Lighting

MA Lighting grandMA2 Light Lighting Console

$10,290.00

The grandMA2 light has 4,096 parameters, 15 motorized executor faders and two touchscreens available. All further features and controls are identical to those on the grandMA2 full-size.

The grandMA2 light is the perfect tool to control all kinds of lighting genres like conventionals, moving lights, LEDs, video and media. It supplies an intuitive and fast control of all connected fixtures and channels. The grandMA2 light can handle an almost infinite number of presets, cues, pages, sequences and effects. It is ideally suited as a standalone console or as a backup device for the grandMA2 full-size. Moreover grandMA series 1-showfiles can be converted to be used with the grandMA2.

All grandMA2 consoles are optionally available as Silent Version with optimised fan for noise-sensitive environments.

View Product Features

  • Real-time control for up to 65,536 parameters per session in connection with MA NPU (equivalent to 256 DMX universes)
  • 4,096 HTP/LTP parameters
  • 6 DMX outputs
  • 2 internal TFT wide mode touchscreens (15.4" WXGA)
  • 2 external TFT screens can be connected (UXGA, touchscreens accepted)
  • 1 internal command screen – multi-touch (9" SVGA)
  • 15 motorized executor faders
  • Integrated keyboard drawer
  • Built-in uninterruptible power supply (UPS)
  • 2 etherCON connectors, 5 USB 2.0 connectors
  • Motorized monitor wing
  • 2 motorized A/B fader (100mm)
  • Individually backlit and dimmable silent (clickless) keys
Out of Stock
0 in stock

Once stock replenishes, inventory will display below.

Already own this item and want to sell it?

About the MA Lighting grandMA2 Light Lighting Console

The MA Lighting grandMA2 light is a professional-grade lighting control console that occupies a pivotal role in the mid-range of the renowned grandMA2 series, offering a powerful and comprehensive feature set for controlling intelligent lighting and visual effects. It is engineered to meet the demanding needs of touring productions, theatrical shows, television studios, and large fixed installations where show reliability and extensive programming capabilities are non-negotiable. The console strikes a careful balance between the expansive power of its larger siblings and a more compact, cost-effective physical footprint, providing a full implementation of the grandMA2 operating system. This means users have access to the same sophisticated software, including a fully-featured 3D visualizer for pre-visualization and the powerful MA-Net2 protocol for commanding thousands of parameters across complex lighting rigs, all from a streamlined hardware interface.

At the heart of its operation is a dedicated processing system that manages multiple universal DMX output universes, extensive cue lists, and complex effect engines with high precision and stability. The console features a combination of tactile controls, including two multi-function playback fader wings with customizable buttons and motorized faders for precise playback control, and two high-resolution multi-touch screens that provide a fluid, intuitive interface for accessing palettes, presets, and fixture parameters. This hybrid physical and touchscreen interface allows lighting designers to work with speed and muscle memory for live playback while retaining deep, menu-driven access for programming and patching. The system’s architecture is built for redundancy and networking, capable of operating in session with other grandMA2 consoles or processing units to create robust, fail-safe control systems for mission-critical events.

Constructed with durability for the road, the console features a robust metal chassis, a responsive mechanical keyboard, and high-quality components designed to withstand the rigors of touring. Its design philosophy centers on providing a professional programmer or operator with a complete, stand-alone tool that does not compromise on software capability. For productions that require powerful, nuanced control of moving lights, LEDs, media servers, and conventional dimmers without the physical size of a full-size console, the grandMA2 light represents an industry-standard solution. It delivers the depth, reliability, and creative freedom that professionals demand, making it a cornerstone for lighting control in a wide array of professional environments.

Key Features

  • Real-time control for up to 65,536 parameters per session in connection with MA NPU (equivalent to 256 DMX universes)
  • 4,096 HTP/LTP parameters
  • 6 DMX outputs
  • 2 internal TFT wide mode touchscreens (15.4" WXGA)
  • 2 external TFT screens can be connected (UXGA, touchscreens accepted)
  • 1 internal command screen – multi-touch (9" SVGA)
  • 15 motorized executor faders
  • Integrated keyboard drawer
  • Built-in uninterruptible power supply (UPS)
  • 2 etherCON connectors, 5 USB 2.0 connectors
  • Motorized monitor wing
  • 2 motorized A/B fader (100mm)
  • Individually backlit and dimmable silent (clickless) keys

MA Lighting grandMA2 Light Lighting Console Specs

Control Interface
Touchscreens
2 x 15.6" High-Resolution
Motorized Faders
10
Programmable Encoders
4
Playback Fader Wings
2
Processing & Output
DMX Universes
4 Universal (Expansible)
Processing Power
Dedicated MA Hardware
Protocol
MA-Net2, Art-Net, sACN
Maximum Parameters
12,288
Physical Build
Chassis Material
Aluminum and Steel
Keyboard
Integrated Mechanical
Transportation
Rackmountable with Flight Case
Power & Connectivity
Mains Input
100-240V AC, 50/60 Hz
Network Ports
4 x Gigabit Ethernet
USB Ports
4 x USB 2.0
Backup Power
Optional UPS Support
Software & Compatibility
Operating Software
grandMA2 v3.x
Integrated Visualizer
MA 3D
Session Compatibility
Full grandMA2 Network
User Profiles
Unlimited

Key Features

  • Real-time control for up to 65,536 parameters per session in connection with MA NPU (equivalent to 256 DMX universes)
  • 4,096 HTP/LTP parameters
  • 6 DMX outputs
  • 2 internal TFT wide mode touchscreens (15.4" WXGA)
  • 2 external TFT screens can be connected (UXGA, touchscreens accepted)
  • 1 internal command screen – multi-touch (9" SVGA)
  • 15 motorized executor faders
  • Integrated keyboard drawer
  • Built-in uninterruptible power supply (UPS)
  • 2 etherCON connectors, 5 USB 2.0 connectors
  • Motorized monitor wing
  • 2 motorized A/B fader (100mm)
  • Individually backlit and dimmable silent (clickless) keys
