SKU: C1917-404

Multiview AK1500 DP High Performance UTP Receiver

$0.00

Items Included

Item Notes

Condition: Out of stock

Once stock replenishes, inventory will display below.

Pre-Owned Guarantee 14 Day Return Window

Trade-In & SAVE Click Here To Get Started

Description

The Magenta Research MultiView AK1500 DP is a high-performance analog video, audio, and serial data extension receiver. Paired with a MultiView Universal Transmitter, this system uses standard Unshielded Twisted Pair (UTP) Category cable (Cat5/Cat5e/Cat6) to distribute high-resolution signals over extreme distances for professional AV installations. Read more

Features

High performance architecture extends clean AV signals up to 1500 feet over standard UTP Cat5 or Cat6 cabling
Integrated Delta Peak skew compensation adjusts individual RGB color channels to fix long distance alignment issues
Universal transmitter interface accepts multiple analog video inputs including RGBHV component and composite video
Dual destination output capability delivers synchronized video audio and serial data to remote displays
Bi directional RS 232 serial routing supports remote touchscreen control display automation and hardware polling

Business Financing Options Avaiable

View Available Financing

Description

Features

High performance architecture extends clean AV signals up to 1500 feet over standard UTP Cat5 or Cat6 cabling
Integrated Delta Peak skew compensation adjusts individual RGB color channels to fix long distance alignment issues
Universal transmitter interface accepts multiple analog video inputs including RGBHV component and composite video
Dual destination output capability delivers synchronized video audio and serial data to remote displays
Bi directional RS 232 serial routing supports remote touchscreen control display automation and hardware polling

No products currently in stock

About the Multiview AK1500 DP High Performance UTP Receiver

The MultiView AK1500 DP is a high-performance, professional-grade UTP (Unshielded Twisted Pair / Cat5) video receiver designed for large-scale AV distribution. Acting as the endpoint of the MultiView extension system, it receives high-resolution analog video signals from a remote transmitter over standard network cable, making it a critical component for digital signage, stadium concourse displays, and sprawling corporate campuses.

Because running heavy, fragile VGA or analog component cables over hundreds of feet introduces severe signal degradation and exorbitant installation costs, AV integrators rely on UTP extension systems. The AK1500 DP solves the distance barrier by utilizing proprietary RepliSync and equalization technologies to push pristine UXGA video up to 1,500 feet over a single, inexpensive Cat5 cable. Furthermore, the "DP" (Dual Port) designation means the receiver acts as an active repeater, allowing technicians to daisy-chain multiple receivers together on a single run to feed a massive corridor of monitors without needing a separate distribution amplifier at every stop.

Key Features

High performance architecture extends clean AV signals up to 1500 feet over standard UTP Cat5 or Cat6 cabling
Integrated Delta Peak skew compensation adjusts individual RGB color channels to fix long distance alignment issues
Universal transmitter interface accepts multiple analog video inputs including RGBHV component and composite video
Dual destination output capability delivers synchronized video audio and serial data to remote displays
Bi directional RS 232 serial routing supports remote touchscreen control display automation and hardware polling
