SKU: 2105-540

PowerCon NAC3FCB to AC Cable

$19.95

Items Included

PowerCon NAC3FCB to AC Cable

Item Notes

Condition: Fully Working 5 availableⓘ

5 availableⓘ View All

Note: Each item is unique. please check individual listings for details.

Pre-Owned Guarantee 14 Day Return Window

Trade-In & SAVE Click Here To Get Started

Description

The Neutrik powerCON NAC3FCB to AC Cable is a rugged, tour-grade power link engineered to safely daisy-chain and extend electricity away from specialized entertainment hardware. Featuring a grey, keyed twist-lock powerCON Type B output connector on one end and a standard 3-prong AC wall plug on the other, this heavy-duty assembly acts as a crucial electrical bridge. Built to withstand the physical demands of live stage setups, touring production rigs, and architectural lighting layouts, it permits technicians to confidently pull power out of an active fixture's output link and route it cleanly into any conventional wall socket or power distribution bank. Read more

Features

Adapts industrial gray twist-lock power-out ports seamlessly into a universal, everyday 3-prong standard AC wall plug configuration.
Delivers superior continuous current flow using high-capacity, heavy-duty 14 AWG internal copper conductors built for high-draw fixtures.
Eliminates connection failures caused by severe stage sub-bass vibrations through an ultra-secure, chuck-style strain relief twist mechanism.
Minimizes extreme external structural degradation over long-term production use utilizing a robust, heavy-duty SJT jacket layout.
Prevents catastrophic shortcut hazards and dangerous cross-wiring using an explicitly keyed gray housing that blocks input-jack mismatching.
Safely provides reliable structural safety inside crowded indoor event arenas utilizing a certified UL94 V-0 flame-retardant formulation.

Business Financing Options Avaiable

View Available Financing

Features

Adapts industrial gray twist-lock power-out ports seamlessly into a universal, everyday 3-prong standard AC wall plug configuration.
Delivers superior continuous current flow using high-capacity, heavy-duty 14 AWG internal copper conductors built for high-draw fixtures.
Eliminates connection failures caused by severe stage sub-bass vibrations through an ultra-secure, chuck-style strain relief twist mechanism.
Minimizes extreme external structural degradation over long-term production use utilizing a robust, heavy-duty SJT jacket layout.
Prevents catastrophic shortcut hazards and dangerous cross-wiring using an explicitly keyed gray housing that blocks input-jack mismatching.
Safely provides reliable structural safety inside crowded indoor event arenas utilizing a certified UL94 V-0 flame-retardant formulation.

No products currently in stock

About the PowerCon NAC3FCB to AC Cable

The PowerCON NAC3FCB to AC Cable is a professional power connection assembly designed to provide a secure AC power interface between equipment fitted with a compatible Neutrik powerCON B-type inlet and a standard AC mains supply. The NAC3FCB connector uses a locking mechanism that helps prevent accidental disconnection during operation, making the cable particularly suitable for professional audio, lighting, broadcast, video, touring, stage, and event-production environments where reliable power retention is important.

The powerCON B-type connector is designed for power-out applications and provides a robust three-contact configuration for line, neutral, and protective earth. Its quick-lock coupling system allows rapid mating and release while maintaining positive mechanical retention once connected. This makes it especially useful for equipment racks, powered loudspeakers, LED fixtures, distribution equipment, and other professional systems that experience frequent installation, transportation, and teardown cycles.

The cable assembly provides a practical connection between compatible powerCON equipment and AC distribution infrastructure. Its grounded configuration supports safe operation with compatible Class I equipment, while the professional connector construction is designed to withstand the mechanical demands of live production and installation environments. Depending on the specific cable configuration, the AC supply end may terminate in an appropriate mains plug or distribution connector selected for the intended electrical system.

The NAC3FCB-to-AC configuration is intended for professional power-distribution applications rather than general-purpose consumer extension use. Correct connector type, cable rating, mains voltage, current capacity, and local electrical requirements should be verified before installation. When used with compatible equipment and properly rated infrastructure, it provides a secure, serviceable solution for professional AC power connectivity.

Key Features

Adapts industrial gray twist-lock power-out ports seamlessly into a universal, everyday 3-prong standard AC wall plug configuration.
Delivers superior continuous current flow using high-capacity, heavy-duty 14 AWG internal copper conductors built for high-draw fixtures.
Eliminates connection failures caused by severe stage sub-bass vibrations through an ultra-secure, chuck-style strain relief twist mechanism.
Minimizes extreme external structural degradation over long-term production use utilizing a robust, heavy-duty SJT jacket layout.
Prevents catastrophic shortcut hazards and dangerous cross-wiring using an explicitly keyed gray housing that blocks input-jack mismatching.
Safely provides reliable structural safety inside crowded indoor event arenas utilizing a certified UL94 V-0 flame-retardant formulation.

Already own this item and want to sell it?

Click here to sell your item

PowerCon NAC3FCB to AC Cable Specs

Electrical

Connector Rated Current

20 A RMS

Connector Rated Voltage

250 V AC

Number of Contacts

Contact Configuration

Line / Neutral / Protective Earth

Contact Resistance

≤ 3 mΩ

Dielectric Strength

4 kV DC

Insulation Resistance

>0.1 GΩ

Connectors

Equipment Connector

NAC3FCB

Connector Type

powerCON B-Type

Connector Gender

Female

Mains Connection

AC Power Plug

Locking System

Quick Lock

Mechanical

Mating Cycles

>1,000

Contact Count

Configuration

Straight

Materials

Contact Material

Bronze

Contact Plating

Silver

Shell Material

Polyamide

Locking Element

Steel

Environmental

Operating Temperature

-30 to +80 °C

Flammability Rating

UL 94 V-0

Protection Rating

IP20, Mated

Key Features

Adapts industrial gray twist-lock power-out ports seamlessly into a universal, everyday 3-prong standard AC wall plug configuration.
Delivers superior continuous current flow using high-capacity, heavy-duty 14 AWG internal copper conductors built for high-draw fixtures.
Eliminates connection failures caused by severe stage sub-bass vibrations through an ultra-secure, chuck-style strain relief twist mechanism.
Minimizes extreme external structural degradation over long-term production use utilizing a robust, heavy-duty SJT jacket layout.
Prevents catastrophic shortcut hazards and dangerous cross-wiring using an explicitly keyed gray housing that blocks input-jack mismatching.
Safely provides reliable structural safety inside crowded indoor event arenas utilizing a certified UL94 V-0 flame-retardant formulation.
