SKU: Digiface Dante

RME Digiface Dante 256-Channel Dante to MADI Audio Interface with USB

$1,749.00

Items Included

Item Notes

Condition: Fully Working 5 availableⓘ
5 availableⓘ View All
Note: Each item is unique. please check individual listings for details.
Pricing
Add to cart
Pre-Owned Guarantee 14 Day Return Window
Trade-In & SAVE Click Here To Get Started

Description

The RME Digiface Dante 256-Channel Dante to MADI Audio Interface with USB is a portable, high-channel-count USB 3.0 device that efficiently bridges Dante and MADI network audio systems, delivering low-latency performance and extensive routing capabilities.  The Digiface Dante is a lightweight, mobile audio interface that combines the popular Dante Audio-over-IP protocol with RME's renowned USB 3.0 technology and MADI connectivity. It offers up to 128 input and 128 output channels (64 each for Dante and MADI) at sample rates up to 192 kHz, all manageable via a single USB 3.0 connection to a Mac or Windows computer. The unit features RME's powerful TotalMix FX mixer software, which provides unlimited routing and mixing options with zero latency, as well as remote control capabilities via TotalMix Remote. The device can also function in a standalone mode as a 64-channel Dante-to-MADI converter, and its four RJ45 Ethernet ports can act as a network switch or provide redundant network operation for enhanced reliability.  Read more

Features

  • 128 inputs and 128 outputs via Dante MADI
  • Four Dante ports and two BNC MADI/Word Clock
  • High-quality headphone output for precise monitoring or mixdown
  • TotalMix FX for zero-latency routing mixing and monitoring
  • Standalone 64-channel Dante/MADI converter without USB

Business Financing Options Avaiable

View Available Financing

The RME Digiface Dante 256-Channel Dante to MADI Audio Interface with USB is a portable, high-channel-count USB 3.0 device that efficiently bridges Dante and MADI network audio systems, delivering low-latency performance and extensive routing capabilities.  The Digiface Dante is a lightweight, mobile audio interface that combines the popular Dante Audio-over-IP protocol with RME's renowned USB 3.0 technology and MADI connectivity. It offers up to 128 input and 128 output channels (64 each for Dante and MADI) at sample rates up to 192 kHz, all manageable via a single USB 3.0 connection to a Mac or Windows computer. The unit features RME's powerful TotalMix FX mixer software, which provides unlimited routing and mixing options with zero latency, as well as remote control capabilities via TotalMix Remote. The device can also function in a standalone mode as a 64-channel Dante-to-MADI converter, and its four RJ45 Ethernet ports can act as a network switch or provide redundant network operation for enhanced reliability.  Read more

Features

  • 128 inputs and 128 outputs via Dante MADI
  • Four Dante ports and two BNC MADI/Word Clock
  • High-quality headphone output for precise monitoring or mixdown
  • TotalMix FX for zero-latency routing mixing and monitoring
  • Standalone 64-channel Dante/MADI converter without USB

Recommended Accessories

    No products currently in stock

Frequently Purchased Together

    No products currently in stock

About the RME Digiface Dante 256-Channel Dante to MADI Audio Interface with USB

Dante is an audio over IP protocol by Audinate. The Digiface Dante is a USB 3.0 from/to Dante interface, adding an external and fully mobile option to the internally used Dante PCIe card. Digiface Dante uses RME's matured MADIface Series driver for Windows and macOS, with lowest latency and industry leading stability. Equipped with the latest TotalMix FX it can not only route, but also mix as many independent submixes as outputs are available. The included high quality phones output offers a quick listen to any audio channel, but can also be used as line output to provide an additional analog stereo mixdown. Equipped with the largest Dante module 64 channel can be sent and received via network.

Key Features

  • 128 inputs and 128 outputs via Dante MADI
  • Four Dante ports and two BNC MADI/Word Clock
  • High-quality headphone output for precise monitoring or mixdown
  • TotalMix FX for zero-latency routing mixing and monitoring
  • Standalone 64-channel Dante/MADI converter without USB

Already own this item and want to sell it?

Click here to sell your item

RME Digiface Dante 256-Channel Dante to MADI Audio Interface with USB Specs

Gigabit Ethernet Port
RJ45
100 Mbit/s, 1 Gbit/s
Standard port LEDs
yellow connected, green data transmission
Supports straight and crossover cables (Auto MDI-X)
Network-based remote control of the unit (TotalMix Remote)
MADI Input
Coaxial via BNC, 75 Ohm, according to AES10-1991
High-sensitivity input stage (< 0.2 Vpp)
Accepts 56 channel and 64 channel mode, plus 96k Frame
Standard
up to 64 channels 24 bit 48 kHz
S/MUX
up to 32 channels 24 bit 96 kHz
S/MUX4
up to 16 channels 24 bit 192 kHz
Lock range
25 kHz – 54 kHz
MADI Output
Coaxial via BNC, 75 Ohm, according to AES10-1991
Output voltage 400 mVpp
Cable length
up to 50 m
Generates 56 channel and 64 channel mode, plus 96k Frame
Standard
up to 64 channels 24 bit 48 kHz
S/MUX / 96k Frame
up to 32 channels 24 bit 96 kHz
S/MUX4
up to 16 channels 24 bit 192 kHz
Word Clock In
BNC, not terminated (10 kOhm)
Switchable internal termination 75 Ohm
Automatic Double/Quad Speed detection and conversion to Single Speed
Word Clock Out
BNC
Max level
5 Vss
Level with termination 75 Ohm
4.0 Vss
Internal impedance
10 Ohm
Digital
Clocks
Internal, Dante, Word, MADI
Supported sample rates
44.1 kHz up to 192 kHz

Key Features

  • 128 inputs and 128 outputs via Dante MADI
  • Four Dante ports and two BNC MADI/Word Clock
  • High-quality headphone output for precise monitoring or mixdown
  • TotalMix FX for zero-latency routing mixing and monitoring
  • Standalone 64-channel Dante/MADI converter without USB
