SKU: V-1HD PLUS

Roland V-1HD PLUS HD Video Switcher - 4 channel HDMI w/ 2XLR and DSK

$769.99

Items Included

Item Notes

Condition: Fully Working 5 availableⓘ
5 availableⓘ View All
Note: Each item is unique. please check individual listings for details.
Pricing
Add to cart
Pre-Owned Guarantee 14 Day Return Window
Trade-In & SAVE Click Here To Get Started

Description

Building on the success of its predecessor, the V-1HD, the V-1HD PLUS features a more advanced and robust design. Its four HDMI inputs with integrated frame rate conversion allow it to mix a variety of sources, such as cameras, computers, tablets, and gaming consoles, with the built-in scaler on input 4 handling problematic sources that don't display correctly. The switcher includes two independent HDMI outputs, which can be configured for a variety of tasks like sending the program feed to a recorder or livestream and using the second output for a multiviewer display. The user-friendly interface is designed for easy operation, with intuitive controls including dedicated buttons for transitions, a T-bar for smooth fades, and eight memory presets for storing and recalling visual layouts. For audio, the V-1HD PLUS boasts a 14-channel digital audio mixer that can mix embedded audio from the HDMI inputs with external audio sources. It includes two XLR inputs with phantom power for professional microphones, as well as an 1/8-inch input for lavalier mics or smartphones and RCA stereo inputs. Each audio input comes with a 3-band EQ, high-pass filter, compressor, noise gate, and sync delay, while the XLR and 1/8-inch inputs also have de-essers for broadcast-quality sound. The powerful four-layer effects engine, featuring a downstream keyer (DSK), supports advanced compositions like picture-in-picture, split screens, and title overlays.  Read more

Features

  • Four HDMI inputs with built-in scalers: Mix a variety of video sources, including cameras and computers, at up to 1080p, with a dedicated scaled input for compatibility.
  • Integrated 14-channel audio mixer: Combine embedded HDMI audio with external mic and line inputs, including two XLR inputs with phantom power, and apply professional-grade effects.
  • Dual independent HDMI outputs: Assign outputs independently for a program feed, multiviewer, or other purposes, providing flexibility for monitoring and recording.
    Powerful 4-layer effects engine: Create professional compositions with picture-in-picture, split screen, chroma/luminance keying, and a DSK for graphics and lower thirds.
  • 10-window multiviewer: Monitor all four video sources, program and preview outputs, and an internal still image bank on a single display.
  • 8 preset memories: Instantly recall complex visual layouts and scene setups with dedicated memory buttons.

Business Financing Options Avaiable

View Available Financing

Building on the success of its predecessor, the V-1HD, the V-1HD PLUS features a more advanced and robust design. Its four HDMI inputs with integrated frame rate conversion allow it to mix a variety of sources, such as cameras, computers, tablets, and gaming consoles, with the built-in scaler on input 4 handling problematic sources that don't display correctly. The switcher includes two independent HDMI outputs, which can be configured for a variety of tasks like sending the program feed to a recorder or livestream and using the second output for a multiviewer display. The user-friendly interface is designed for easy operation, with intuitive controls including dedicated buttons for transitions, a T-bar for smooth fades, and eight memory presets for storing and recalling visual layouts. For audio, the V-1HD PLUS boasts a 14-channel digital audio mixer that can mix embedded audio from the HDMI inputs with external audio sources. It includes two XLR inputs with phantom power for professional microphones, as well as an 1/8-inch input for lavalier mics or smartphones and RCA stereo inputs. Each audio input comes with a 3-band EQ, high-pass filter, compressor, noise gate, and sync delay, while the XLR and 1/8-inch inputs also have de-essers for broadcast-quality sound. The powerful four-layer effects engine, featuring a downstream keyer (DSK), supports advanced compositions like picture-in-picture, split screens, and title overlays.  Read more

Features

  • Four HDMI inputs with built-in scalers: Mix a variety of video sources, including cameras and computers, at up to 1080p, with a dedicated scaled input for compatibility.
  • Integrated 14-channel audio mixer: Combine embedded HDMI audio with external mic and line inputs, including two XLR inputs with phantom power, and apply professional-grade effects.
  • Dual independent HDMI outputs: Assign outputs independently for a program feed, multiviewer, or other purposes, providing flexibility for monitoring and recording.
    Powerful 4-layer effects engine: Create professional compositions with picture-in-picture, split screen, chroma/luminance keying, and a DSK for graphics and lower thirds.
  • 10-window multiviewer: Monitor all four video sources, program and preview outputs, and an internal still image bank on a single display.
  • 8 preset memories: Instantly recall complex visual layouts and scene setups with dedicated memory buttons.

Recommended Accessories

    No products currently in stock

Frequently Purchased Together

    No products currently in stock

About the Roland V-1HD PLUS HD Video Switcher - 4 channel HDMI w/ 2XLR and DSK

The Roland V-1HD PLUS is a professional, all-in-one live video production switcher that combines multi-camera video switching with a professional audio mixer in a remarkably compact and intuitive hardware unit. Designed for live streamers, educators, and content creators, its core function is to seamlessly switch between up to four simultaneous HDMI video sources—such as cameras, computers, or media players—while providing broadcast-style transitions, picture-in-picture effects, and a dedicated downstream keyer (DSK) for overlaying titles and logos. The integrated two-channel audio mixer, featuring two XLR/TRS combo inputs with switchable phantom power, is a defining feature, allowing users to connect microphones, instruments, or line-level audio sources and mix them with the embedded audio from HDMI feeds directly within the switcher, ensuring perfect audio-video synchronization without the need for an external mixer.

Operation is centered on tactile, hands-on control, highlighted by a large, professional T-bar for executing smooth, speed-variable fades and transitions between video sources. The unit provides dedicated buttons for cuts, auto-transitions, and the activation of the picture-in-picture window, making complex production techniques accessible even to solo operators. The downstream keyer allows for the insertion of graphics onto the final program output without affecting the preview monitor, adding a layer of polish to live broadcasts. With ultra-low latency processing and dual HDMI outputs—one for the final program feed and one for preview or auxiliary purposes—the setup facilitates confident live switching and easy multi-destination streaming or local recording.

Engineered for reliability and ease of use, the V-1HD PLUS operates as a standalone device without requiring a computer for its primary functions, offering a plug-and-play solution that significantly elevates production quality. It is an ideal central hub for creating dynamic, multi-source live video for applications such as house of worship services, corporate webinars, online teaching, and live event streaming, delivering a comprehensive suite of video and audio tools in a single, portable unit.

Key Features

  • Four HDMI inputs with built-in scalers: Mix a variety of video sources, including cameras and computers, at up to 1080p, with a dedicated scaled input for compatibility.
  • Integrated 14-channel audio mixer: Combine embedded HDMI audio with external mic and line inputs, including two XLR inputs with phantom power, and apply professional-grade effects.
  • Dual independent HDMI outputs: Assign outputs independently for a program feed, multiviewer, or other purposes, providing flexibility for monitoring and recording.
    Powerful 4-layer effects engine: Create professional compositions with picture-in-picture, split screen, chroma/luminance keying, and a DSK for graphics and lower thirds.
  • 10-window multiviewer: Monitor all four video sources, program and preview outputs, and an internal still image bank on a single display.
  • 8 preset memories: Instantly recall complex visual layouts and scene setups with dedicated memory buttons.

Already own this item and want to sell it?

Click here to sell your item

Roland V-1HD PLUS HD Video Switcher - 4 channel HDMI w/ 2XLR and DSK Specs

Video Inputs
Quantity
4
Connector
HDMI Type A
Max Resolution
1920x1080 (1080p) @ 60Hz
Supported Formats
480p, 576p, 720p, 1080i, 1080p
Video Outputs
Program Output
1 x HDMI
Preview/Aux Output
1 x HDMI
Output Resolution
1080p60 (matches input)
Switching & Effects
Transition Types
Cut, Fade, Wipe (with T-bar and Auto)
Picture-in-Picture
Yes, with position adjustment
Downstream Keyer (DSK)
Yes, 1 channel for titles/logos
Audio Inputs
Microphone/Line Inputs
2 x XLR/TRS combo jacks
Phantom Power
+48V, switchable per channel
HDMI Audio
Embedded audio from all 4 inputs
Audio Mixing & Monitoring
Audio Mixer
Built-in 6-channel mixer (2 XLR, 4 HDMI)
Headphone Output
1 x 1/4-inch stereo jack
Headphone Level Control
Dedicated volume knob
General
Power Supply
DC 12V, 2A
Power Consumption
12W
Dimensions (W x D x H)
280 mm x 186 mm x 58 mm
Weight
1.2 kg
Operating Temperature
5°C to 40°C

Key Features

  • Four HDMI inputs with built-in scalers: Mix a variety of video sources, including cameras and computers, at up to 1080p, with a dedicated scaled input for compatibility.
  • Integrated 14-channel audio mixer: Combine embedded HDMI audio with external mic and line inputs, including two XLR inputs with phantom power, and apply professional-grade effects.
  • Dual independent HDMI outputs: Assign outputs independently for a program feed, multiviewer, or other purposes, providing flexibility for monitoring and recording.
    Powerful 4-layer effects engine: Create professional compositions with picture-in-picture, split screen, chroma/luminance keying, and a DSK for graphics and lower thirds.
  • 10-window multiviewer: Monitor all four video sources, program and preview outputs, and an internal still image bank on a single display.
  • 8 preset memories: Instantly recall complex visual layouts and scene setups with dedicated memory buttons.

Already own this item and want to sell it?

Click here to sell your item

FAQs about Roland V-1HD PLUS HD Video Switcher - 4 channel HDMI w/ 2XLR and DSK
