Tannoy VX 12HP 12" PowerDual Full Range Loudspeaker for Portable and Installation Applications

Name: Tannoy VX 12HP 12" PowerDual Full Range Loudspeaker for Portable and Installation Applications
Brand: AVGear.com
SKU: VX 12HP
Price: 1099.00 USD
Availability: InStock

$1,099.00

Items Included

Item Notes

Condition: Fully Working 5 availableⓘ

5 availableⓘ View All

Note: Each item is unique. please check individual listings for details.

Pre-Owned Guarantee 14 Day Return Window

Trade-In & SAVE Click Here To Get Started

Description

The VX 12HP is built around a single 300 mm (12") PowerDual driver mounted within a compact, rugged plywood cabinet, and renowned for its exceptional performance and versatility. The latest high powerhandling version of TANNOY’s exclusive point source, constant directivity PowerDual technology ensures high power output with high sensitivity and exceptional efficiency. The point source driver technology allows this unique configuration to deliver exceptionally smooth beam-width characteristics resulting in an even coverage pattern aiding predictable system design. Symmetrical dispersion characteristics enhance speaker placement flexibility, allowing vertical or horizontal mounting of single or multi-cabinet arrays without any compromise in sound quality. The VX 12HP is also ideally suited for use complimenting much larger systems, making it an excellent choice for both installed and portable applications. The VX 12HP can also be configured for bi-amp operation.This product is fulfilled and shipped by a third-party supplier. Delivery timelines are estimated and may vary. Please allow up to 10–14 business days for order processing and fulfillment. Read more

Features

Full range multi-purpose sound reinforcement loudspeaker for portable and installation applications
350 Watts continuous, 1,400 Watts peak power
12" PowerDual full range driver for point source phase coherence
Precise 75º dispersion for optimum coverage and forward projection
Ideal for FOH, floor monitor and side fill applications
Configurable for bi-amp operation
Vented and internally braced plywood enclosure
Finished with hard wearing semi matt black paint
Rugged powder coated perforated steel mesh grille
Blanking plate for optional VTH pole mount
Optional horizontal and vertical mounting yokes (available separately)

Business Financing Options Avaiable

View Available Financing

Features

Full range multi-purpose sound reinforcement loudspeaker for portable and installation applications
350 Watts continuous, 1,400 Watts peak power
12" PowerDual full range driver for point source phase coherence
Precise 75º dispersion for optimum coverage and forward projection
Ideal for FOH, floor monitor and side fill applications
Configurable for bi-amp operation
Vented and internally braced plywood enclosure
Finished with hard wearing semi matt black paint
Rugged powder coated perforated steel mesh grille
Blanking plate for optional VTH pole mount
Optional horizontal and vertical mounting yokes (available separately)

No products currently in stock

About the Tannoy VX 12HP 12" PowerDual Full Range Loudspeaker for Portable and Installation Applications

Conceived, engineered and built with precision in the United Kingdom, the VX series represents the latest evolution of Tannoy's core philosophies in professional loudspeaker design. VX12 is a new evolution of Tannoy's market-leading V12, renowned for its exceptional performance and veratility making it a premier choice for many typical applications. It provides a high performance solution for medium scale sound reinforcement and more demanding mixed-use BGM applications such as loud fashion retail outlets, bars and small clubs. The VX12 has also been acoustically matched with the wider range of VX Series models, making it a perfectly capable component within much larger installations.

Key Features

Full range multi-purpose sound reinforcement loudspeaker for portable and installation applications
350 Watts continuous, 1,400 Watts peak power
12" PowerDual full range driver for point source phase coherence
Precise 75º dispersion for optimum coverage and forward projection
Ideal for FOH, floor monitor and side fill applications
Configurable for bi-amp operation
Vented and internally braced plywood enclosure
Finished with hard wearing semi matt black paint
Rugged powder coated perforated steel mesh grille
Blanking plate for optional VTH pole mount
Optional horizontal and vertical mounting yokes (available separately)

Already own this item and want to sell it?

Click here to sell your item

Tannoy VX 12HP 12" PowerDual Full Range Loudspeaker for Portable and Installation Applications Specs

System

Frequency response

70 Hz - 25 kHz ±3 dB55 Hz - 38 kHz -10 dB

Nominal dispersion

90° conical @ -6 dB point

Directivity factor (Q)

9.6

Directivity index (DI)

9.8

Power handling (IEC)

Passive

200 W continuous, 800 W peak

Bi-amp

Sensitivity

97 dB (1 W @ 1 m)

Maximum SPL

Passive

120 dB continuous, 126 dB peak

Bi-amp

Impedance

Passive

8 Ω

Bi-amp

Crossover Type

Passive with HF protection

Components

1 x 12" (305 mm) constant directivityDual Concentric

Enclosure

Connectors

2 x Industry-standard 4-pole twist-lock speaker connectors, 1 x barrier strip terminals

Wiring

Passive

Pins 1+ / 1- Input, Pins 2+ / 2- Link

Bi-Amp

Dimensions H x W x D

487 x 371 x 361 mm(19.2 x 14.6 x 14.2")

Net weight

16.5 kg (36.3 lbs)

Construction

15 mm (5/8") enclosure / 18 mm (3/4")front, plywood, vented andinternally braced

Finish

Semi matt black paint (white optional)

Grille

Powder coated perforated steel

Flying hardware

M10 x 8 flying inserts(portrait or landscape mounting)M10 x 8 yoke bracket inserts2 x Intergrip carrying handles Blanking plate for optional VTH pole mount Compatible with industry standard brackets M6 x 4 inserts

Key Features

Full range multi-purpose sound reinforcement loudspeaker for portable and installation applications
350 Watts continuous, 1,400 Watts peak power
12" PowerDual full range driver for point source phase coherence
Precise 75º dispersion for optimum coverage and forward projection
Ideal for FOH, floor monitor and side fill applications
Configurable for bi-amp operation
Vented and internally braced plywood enclosure
Finished with hard wearing semi matt black paint
Rugged powder coated perforated steel mesh grille
Blanking plate for optional VTH pole mount
Optional horizontal and vertical mounting yokes (available separately)
