SKU: ML-16D

TASCAM ML-16D Dante / Analog Converter

$1,999.00

Items Included

Item Notes

Condition: Fully Working 5 availableⓘ
5 availableⓘ View All
Note: Each item is unique. please check individual listings for details.
Pricing
Add to cart
Pre-Owned Guarantee 14 Day Return Window
Trade-In & SAVE Click Here To Get Started

Description

The ML-16D Dante / Analog Converter from Tascam is a Dante-focused converter designed to insert or extract analog audio into or out of a Dante (Digital Audio Network Through Ethernet) network using external breakout devices that utilize D-Sub format connectors. The Tascam ML-16D has two D-Sub inputs and two D-Sub outputs, that can be used to connect several devices that utilize D-Sub connectors such as microphone preamplifiers, console mixers, audio interfaces, amplifiers, and other audio devices. Furthermore, the Dante protocol provides uncompressed, multi-channel, low-latency digital audio over a standard Ethernet network and supports up to 1024 channels of 32-bit / 192 kHz audio over a Cat 5/6 Ethernet system. Read more

Features

  • Dante-focused interface for connection of external audio in or out of a Dante audio network.
  • 16-channel analog line input and 16 analog line outputs (48 kHz / 96 kHz) using 4 D-Sub connectors.
  • Dual redundant Ethernet jacks which support both primary and secondary connections.
  • Up to 24-bit / 96 kHz quality.
  • LED display for signal level and overload per input/output channel.
  • Reference level dip switches for selectable dBu level metering.
  • Firmware updatable via Dante port.
  • AES67 and Revenna compatible.

Business Financing Options Avaiable

View Available Financing

The ML-16D Dante / Analog Converter from Tascam is a Dante-focused converter designed to insert or extract analog audio into or out of a Dante (Digital Audio Network Through Ethernet) network using external breakout devices that utilize D-Sub format connectors. The Tascam ML-16D has two D-Sub inputs and two D-Sub outputs, that can be used to connect several devices that utilize D-Sub connectors such as microphone preamplifiers, console mixers, audio interfaces, amplifiers, and other audio devices. Furthermore, the Dante protocol provides uncompressed, multi-channel, low-latency digital audio over a standard Ethernet network and supports up to 1024 channels of 32-bit / 192 kHz audio over a Cat 5/6 Ethernet system. Read more

Features

  • Dante-focused interface for connection of external audio in or out of a Dante audio network.
  • 16-channel analog line input and 16 analog line outputs (48 kHz / 96 kHz) using 4 D-Sub connectors.
  • Dual redundant Ethernet jacks which support both primary and secondary connections.
  • Up to 24-bit / 96 kHz quality.
  • LED display for signal level and overload per input/output channel.
  • Reference level dip switches for selectable dBu level metering.
  • Firmware updatable via Dante port.
  • AES67 and Revenna compatible.

Recommended Accessories

    No products currently in stock

Frequently Purchased Together

    No products currently in stock

About the TASCAM ML-16D Dante / Analog Converter

The ML-16D Dante / Analog Converter from Tascam is a Dante-focused converter designed to insert or extract analog audio into or out of a Dante (Digital Audio Network Through Ethernet) network using external breakout devices that utilize D-Sub format connectors.

The Tascam ML-16D has two D-Sub inputs and two D-Sub outputs, that can be used to connect several devices that utilize D-Sub connectors such as microphone preamplifiers, console mixers, audio interfaces, amplifiers, and other audio devices.

Furthermore, the Dante protocol provides uncompressed, multi-channel, low-latency digital audio over a standard Ethernet network and supports up to 1024 channels of 32-bit / 192 kHz audio over a Cat 5/6 Ethernet system.

Key Features

  • Dante-focused interface for connection of external audio in or out of a Dante audio network.
  • 16-channel analog line input and 16 analog line outputs (48 kHz / 96 kHz) using 4 D-Sub connectors.
  • Dual redundant Ethernet jacks which support both primary and secondary connections.
  • Up to 24-bit / 96 kHz quality.
  • LED display for signal level and overload per input/output channel.
  • Reference level dip switches for selectable dBu level metering.
  • Firmware updatable via Dante port.
  • AES67 and Revenna compatible.

Already own this item and want to sell it?

Click here to sell your item

TASCAM ML-16D Dante / Analog Converter Specs

General
Channels of I/O
16 Input / 16 Output
Built-In DSP
No
Maximum Sampling Rate
96 kHz / 24-Bit
Number of Microphone Inputs
No
Built-In Microphone
No
Connectivity
Analog Audio I/O
2x DB-25 8-Channel Input 2x DB-25 8-Channel Output
Digital Audio I/O
No
Host Connection / USB
No
Host Connection Protocol
No
USB (Non-Host)
No
Sync I/O
No
Network I/O
2x RJ45 Dante
MIDI I/O
No
Performance
Frequency Response
20 Hz to 20 kHz +0.1/-0.5 dB (at 48 kHz, JEITA) 20 Hz to 40 kHz +0.1/-0.5 dB (at 96 kHz, JEITA)
Impedance
DB-25 Inputs: ≥ 10 Kilohms
SNR
113 dB
THD+N
0.001%
Digital Audio
Sample Rates
44.1 to 96 kHz
Sample Rate Conversion
No
Bit Depths
16 / 24-Bit
Compatibility
OS Compatibility
Windows / macOS
Power
AC Input Power
100 to 240 VAC, 50 / 60 Hz
Power Consumption
22 W
Physical
Rackmount Size
1 U
Operating Conditions
32 to 104°F / 0 to 40°C
Dimensions
19 x 12 x 1.8" / 483 x 303.8 x 45 mm
Weight
7.7 lb / 3.5 kg

Key Features

  • Dante-focused interface for connection of external audio in or out of a Dante audio network.
  • 16-channel analog line input and 16 analog line outputs (48 kHz / 96 kHz) using 4 D-Sub connectors.
  • Dual redundant Ethernet jacks which support both primary and secondary connections.
  • Up to 24-bit / 96 kHz quality.
  • LED display for signal level and overload per input/output channel.
  • Reference level dip switches for selectable dBu level metering.
  • Firmware updatable via Dante port.
  • AES67 and Revenna compatible.
