SKU: Theatrixx-XVV2SDI2FIBER-12GS2

Theatrixx Technologies Dual 12G-SDI to Dual Fiber xVision Converter (Single-Mode, OpticalCON Dual)

$2,560.00

Items Included

Item Notes

Condition: Fully Working 5 available
5 available View All
Note: Each item is unique. please check individual listings for details.
Pricing
Add to cart
Pre-Owned Guarantee 14 Day Return Window

Description

The Dual 12G-SDI to Dual Fiber xVision Converter from Theatrixx Technologies is a sturdy, compact plug-and-play converter that offers a quad 12G-SDI input to a single-mode opticalCON dual SFP fiber output module for video conversion over long-distances. The unit features an integrated power supply with a locking powerCON True1 connector and a built-in standard AC outlet to power a nearby projector, TV, or laptop. There is also a loop-through powerCON True1 output to daisy-chain your modules or power a local TV, computer, or projector. Read more

Features

  • Plug-and-Play Operation
  • 12G-SDI to SFP Fiber Video Transmission
  • Single-Mode Fiber Connection Type
  • OpticalCON Dual Connector Output
  • Multiple Mounting Options
  • Magnetic Stacking System
  • PowerCON True1 Power Input/Loop Output

Business Financing Options Avaiable

The Dual 12G-SDI to Dual Fiber xVision Converter from Theatrixx Technologies is a sturdy, compact plug-and-play converter that offers a quad 12G-SDI input to a single-mode opticalCON dual SFP fiber output module for video conversion over long-distances. The unit features an integrated power supply with a locking powerCON True1 connector and a built-in standard AC outlet to power a nearby projector, TV, or laptop. There is also a loop-through powerCON True1 output to daisy-chain your modules or power a local TV, computer, or projector. Read more

Features

  • Plug-and-Play Operation
  • 12G-SDI to SFP Fiber Video Transmission
  • Single-Mode Fiber Connection Type
  • OpticalCON Dual Connector Output
  • Multiple Mounting Options
  • Magnetic Stacking System
  • PowerCON True1 Power Input/Loop Output

About the Theatrixx Technologies Dual 12G-SDI to Dual Fiber xVision Converter (Single-Mode, OpticalCON Dual)

Professional equipment in mission-critical applications is all about reliability and confidence. So Theatrixx started with a clean sheet, and built what might soon become your most trustwor- thy piece of equipment.

Introducing the world's first video converters truly designed for the road. Video converters nowadays are used everywhere on profesionnal A/V events, presentations, live shows and tours and often have a critical role.

Yet, they are often the weakest link in the signal chain. Low quality connectors, weak enclosure, external consumer-grade power supply, and overall barebones design that all contribute to a generally unreliable piece of equipment. They wanted to change that, so they designed the xVision Video Converters.

Key Features

  • Plug-and-Play Operation
  • 12G-SDI to SFP Fiber Video Transmission
  • Single-Mode Fiber Connection Type
  • OpticalCON Dual Connector Output
  • Multiple Mounting Options
  • Magnetic Stacking System
  • PowerCON True1 Power Input/Loop Output

Theatrixx Technologies Dual 12G-SDI to Dual Fiber xVision Converter (Single-Mode, OpticalCON Dual) Specs

Connections
Video Input
2 x 12G/6G/3G/HD/SD SDI BNC
Loop-thru
2 x 12G/6G/3G/HD/SD SDI BNC
Video Output
Singlemode - Optical SDI on OpticalCON DUO
Supported Signals
Video Format
12G/6G/3G-SDI Level A and B, HD-SDI, SD-SDI with embedded audio
SMPTE Standards
2082-1, 2082-10, 425 M Level A & B, 424 M, 292 M, 259 M
Physical
Height
62 mm (2.44 in)
Depth
180 mm (7.08 in)
Width
221 mm (8.7 in)
Weight
2 kg (4.4 lbs)
Alternate Form Factor
Also available as a Reversible Module
Environmental
Relative Humidity
0% to 90% non-condensing
Operating Temperature
0-40 °C
Power Requirements
Power Supply
Built-in power supply - PowerCon True1 input, PowerCON True1 output (loop-thru)
Power Consumption
45W max.
Operational Voltage Range
100-240V, 50-60Hz
Courtesy Outlet
Max 10 A, same voltage as input

Key Features

  • Plug-and-Play Operation
  • 12G-SDI to SFP Fiber Video Transmission
  • Single-Mode Fiber Connection Type
  • OpticalCON Dual Connector Output
  • Multiple Mounting Options
  • Magnetic Stacking System
  • PowerCON True1 Power Input/Loop Output
