Theatrixx Technologies

Theatrixx Technologies Dual Channel Fiber to 3G-SDI (PT1 In/Thru, Multimode, OpticalCON Quad)

$1,670.00

Theatrixx Technologies Dual Channel Fiber to 3G-SDI (PT1 In/Thru, Multimode, OpticalCON Quad)

View Product Features

Reclocked and amplified SDI Loop Thru
Integrated power supply with locking PowerCON connector. Never rely on a cluster of wall-warts again.
Built-in convenience 120V outlet to power nearby projector, TV, laptop, small video projector. Power bar to power both the converter and device not required anymore.
Magnetic stacking system and non-skid rubber pad. Saves at least 10 gaffer tape rolls a year.
Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adaptor.
Rugged, Tour-ready and aesthetic enclosure: The sexiest widget in your tool box, that will keep looking good for years to come.
Plug-n-play operation; No dipswitches, buttons or menus to fumble with: It just works.
Clear and ample status LED indicators for quick troubleshooting.
Easy on-the-field identification with unique color and alphabetic coding system.
Locking HDMI port prevents accidental disconnection.

In stock

Scroll below to see our current inventory for this item.

In-Stock Inventory

New
Theatrixx-XVV2FIBER2SDI-M3

Theatrixx Technologies Dual Channel Fiber to 3G-SDI (PT1 In/Thru, Multimode, OpticalCON Quad)

$1,670.00

View Product

Already own this item and want to sell it?

Click here to sell your item

About the Theatrixx Technologies Dual Channel Fiber to 3G-SDI (PT1 In/Thru, Multimode, OpticalCON Quad)

Professional equipment in mission-critical applications is all about reliability and confidence, the xVision SDI to HDMI Converter is built with a super rugged chassis and it's designed to be your most trustworthy piece of equipment. It features a single SDI input with dual SDI & single HDMI outputs.

Key Features

Reclocked and amplified SDI Loop Thru
Integrated power supply with locking PowerCON connector. Never rely on a cluster of wall-warts again.
Built-in convenience 120V outlet to power nearby projector, TV, laptop, small video projector. Power bar to power both the converter and device not required anymore.
Magnetic stacking system and non-skid rubber pad. Saves at least 10 gaffer tape rolls a year.
Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adaptor.
Rugged, Tour-ready and aesthetic enclosure: The sexiest widget in your tool box, that will keep looking good for years to come.
Plug-n-play operation; No dipswitches, buttons or menus to fumble with: It just works.
Clear and ample status LED indicators for quick troubleshooting.
Easy on-the-field identification with unique color and alphabetic coding system.
Locking HDMI port prevents accidental disconnection.

Theatrixx Technologies Dual Channel Fiber to 3G-SDI (PT1 In/Thru, Multimode, OpticalCON Quad) Specs

Connections

Video Input

3G/HD/SD SDI BNC

Video Output

HDMI 1.2 type A with lock system, 2 x 3G/HD/SD SDI BNC

Supported Signals

3G Format Support

1080p50, 1080p59.94, 1080p60.

HD Format Support

720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080PsF23.98, 1080p24, 1080PsF24, 1080p25, 1080PsF25, 1080p29.97, 1080PsF29.97, 1080p30, 1080PsF30

SD Format Support

525/23.98 NTSC, 525/29.97 NTSC.625/25 PAL.

SDI Video Sampling

4:2:2 and 4:4:4

SDI Audio Sampling

Sample rate of 48 kHz and 24 bit.

SDI Color Space

YUV and RGB

SDI Auto Switching

Automatically detects incoming signal format.

Power Requirements

Power Supply

Built-in power supply, PowerCON input, Edison Nema 5-15 output

Power Consumption

25W

Operational Voltage Range

90-125V, 90-250V also available (with PowerCON True1)

Physical Specifications

Height

50mm (1.97in)

Depth

180mm (7.08in)

Width

107mm (4.21in)

Weight

1kg (2.2lbs)

Relative Humidity

0% to 90% non-condensing

Key Features

Reclocked and amplified SDI Loop Thru
Integrated power supply with locking PowerCON connector. Never rely on a cluster of wall-warts again.
Built-in convenience 120V outlet to power nearby projector, TV, laptop, small video projector. Power bar to power both the converter and device not required anymore.
Magnetic stacking system and non-skid rubber pad. Saves at least 10 gaffer tape rolls a year.
Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adaptor.
Rugged, Tour-ready and aesthetic enclosure: The sexiest widget in your tool box, that will keep looking good for years to come.
Plug-n-play operation; No dipswitches, buttons or menus to fumble with: It just works.
Clear and ample status LED indicators for quick troubleshooting.
Easy on-the-field identification with unique color and alphabetic coding system.
Locking HDMI port prevents accidental disconnection.
