Vari-Lite

Vari-Lite VL2500 100-240VAC 12A 50/60Hz Spot Moving Light w/ True1 Connector

$0.00

The VL2500 Spot is a compact yet powerful moving-head spotlight, descended from the renowned Series 2000 fixtures. It packs a 700W short-arc lamp into a lightweight body (~59lb), delivering high-output lumens, fast motorized zoom (18.5°-42°), and enhanced color, gobo, and iris control-perfect for touring, theatrical, and event lighting.

View Product Features

  • 700W short-arc lamp with 5600K color temperature and roughly 14,500lumens output
  • Motorized zoom spanning 18.5°–42°, with programmable zoom timing from 2sec to 20min
  • Three-wheel CYM color mixing plus an 11-position color wheel for virtually limitless color options
  • Dual-gobo wheels: one with 5 rotating/indexable gobos, one with 11 fixed gobos, plus pattern and edge focus control
  • Glass dimmer wheel for smooth full-range dimming (100–0%) and a dual-blade strobe capable of ultra-fast, quiet operation
  • Mechanical iris offers beam size control with rapid or smooth changes
  • Fast, precise pan (540°) and tilt (270°) via three-phase stepper motors, with 0.3° positional resolution
  • Compact and lightweight design (~59lb) with robust optics and forced-air cooling—mountable in any orientation
  • DMX512/Art-Net compatible, with built-in processors, diagnostics, and self-calibration routines
  • True1 power connector supports 100–240VAC, 12A power input
Out of Stock
0 in stock

Once stock replenishes, inventory will display below.

Already own this item and want to sell it?

About the Vari-Lite VL2500 100-240VAC 12A 50/60Hz Spot Moving Light w/ True1 Connector

The Vari-Lite VL2500 is a high-performance, automated spot moving light designed for professional stage, television, and touring applications, renowned for its bright output, smooth movement, and extensive feature set. As part of the acclaimed Vari-Lite series, it incorporates a powerful discharge lamp source coupled with advanced optical systems to produce a crisp, intense beam capable of long throws and sharp gobo projections. The fixture's defining characteristic is its fully enclosed IP-rated design, which provides superior protection against dust and moisture, making it exceptionally reliable for use in demanding environments, both indoors and outdoors. Its sophisticated mechanical system offers fast, silent pan and tilt movement with high precision, enabling dynamic, fluid lighting cues that are a staple of large-scale productions.

At the core of the VL2500's functionality is its rich array of creative tools, including two independently rotating gobo wheels with indexing capability, a full-range variable CTO color temperature correction system, a linear color-mixing system for a vast range of saturated hues, and a high-resolution dimmer and strobe system for precise intensity control. The fixture also features a motorized zoom and focus system, allowing the beam angle to be adjusted from a tight pin spot to a wide wash without sacrificing edge sharpness. These attributes are managed through a sophisticated onboard control system that can be operated via industry-standard DMX512 protocol or through Vari-Lite's proprietary VLC network, offering designers deep programming flexibility and reliable show playback.

Built for integration into large, power-managed lighting rigs, the fixture utilizes the proprietary True1 connector system, which consolidates power, data, and safety earth into a single, robust connection for streamlined and safe touring deployment. The VL2500's combination of high output, environmental resilience, mechanical speed, and extensive feature set has established it as a workhorse in the automated lighting world. It is engineered to deliver consistent, reliable performance night after night, providing lighting designers with a versatile and powerful tool to realize ambitious visual concepts in the most challenging production scenarios.

Key Features

  • 700W short-arc lamp with 5600K color temperature and roughly 14,500lumens output
  • Motorized zoom spanning 18.5°–42°, with programmable zoom timing from 2sec to 20min
  • Three-wheel CYM color mixing plus an 11-position color wheel for virtually limitless color options
  • Dual-gobo wheels: one with 5 rotating/indexable gobos, one with 11 fixed gobos, plus pattern and edge focus control
  • Glass dimmer wheel for smooth full-range dimming (100–0%) and a dual-blade strobe capable of ultra-fast, quiet operation
  • Mechanical iris offers beam size control with rapid or smooth changes
  • Fast, precise pan (540°) and tilt (270°) via three-phase stepper motors, with 0.3° positional resolution
  • Compact and lightweight design (~59lb) with robust optics and forced-air cooling—mountable in any orientation
  • DMX512/Art-Net compatible, with built-in processors, diagnostics, and self-calibration routines
  • True1 power connector supports 100–240VAC, 12A power input

Vari-Lite VL2500 100-240VAC 12A 50/60Hz Spot Moving Light w/ True1 Connector Specs

Light Source & Output
Lamp Type
MSR 700W FastFit Discharge
Nominal Luminous Flux
18,000 Lumens
Beam Angle (Zoom Range)
9° - 28°
Color System
CMY Mixing + Fixed Colors
Optical Features
Gobo Wheels
2 (Rotating/Indexing)
Gobo Capacity
7 + 7
Color Temperature Correction
Full-range CTO
Strobe
0-20 Hz Variable Speed
Movement & Control
Pan Range
540°
Tilt Range
270°
Pan/Tilt Speed
High Torque Direct Drive
Control Protocols
DMX512, VLC Network
Electrical & Connector
Power Supply
100-240V AC, 50/60 Hz
Power Consumption
850W (Maximum)
Data/Power Connector
True1 (5-pin)
Physical & Environmental
Housing
IP65 Rated (Protected)
Dimensions
24.8" x 15.7" x 13.4"
Weight
68 lbs (30.8 kg)
Cooling
Internal Forced Air

Key Features

  • 700W short-arc lamp with 5600K color temperature and roughly 14,500lumens output
  • Motorized zoom spanning 18.5°–42°, with programmable zoom timing from 2sec to 20min
  • Three-wheel CYM color mixing plus an 11-position color wheel for virtually limitless color options
  • Dual-gobo wheels: one with 5 rotating/indexable gobos, one with 11 fixed gobos, plus pattern and edge focus control
  • Glass dimmer wheel for smooth full-range dimming (100–0%) and a dual-blade strobe capable of ultra-fast, quiet operation
  • Mechanical iris offers beam size control with rapid or smooth changes
  • Fast, precise pan (540°) and tilt (270°) via three-phase stepper motors, with 0.3° positional resolution
  • Compact and lightweight design (~59lb) with robust optics and forced-air cooling—mountable in any orientation
  • DMX512/Art-Net compatible, with built-in processors, diagnostics, and self-calibration routines
  • True1 power connector supports 100–240VAC, 12A power input
